WIRELESS PD POWER BANK
USER MANUAL
Thank you for purchasing our product, and we hope you will enjoy it.

Product description

Input/Output 1 (Type-C): 5 V/3 A, 9 V/2 A, 12 V/1.5 A (18 W max.)
Output 2 (Lightning): 5 V/3 A
Output 2 (USB-A): 5 V/3 A, 9 V/2 A, 12 V/1.5 A (18 W max.)
Wireless charging: 5 W/7.5 W/10 W
Material: ABS, rubberized plastic
Product dimensions: 72 x 139 x 17 mm
Weight: 219 g
Package content
1x Epico Wireless PD Power Bank
1x USB-C cable
1x Anti-slip mat
1x user manual
Battery charge indication
1 LED: 0–25%
2 LED: 25-50%
A green LED light indicates that wireless charging is active.
A blue LED light indicates the detection of charging options.
Double tapping the on/off button will turn the power bank off.
User manual
Charging external batteries:
1. Connect the external battery to the adapter (max. 2A) using the included cable.
2. When charging is on, the LED diode indicating the charge status will flash in white.
3. Once the power bank is fully charged, the diodes will stop flashing and will instead emit a continuous white light.
4. Disconnect the power bank from electricity once it is fully charged.
Charging mobile devices using a cable:
1. You can charge your mobile device via USB-C or USB-A output.
2. USB-C port supports the Power Delivery technology with a charging power output of up to 18W.
3. USB-A port supports the Fast Charge technology with a charging power output of up to 18W.
4. Pressing the on/off button 1x turns the power bank on.
5. Connect your mobile device using the cable to the appropriate power bank port.
6. When recharging, the white LED diodes indicate the remaining battery charge.
7. After charging is complete, disconnect your device from the power bank and double-tap the on/off
button to turn the power bank off.
Wireless charging:
The power bank supports the wireless charging Qi standard with a power output of 5 W/7.5 W/10 W.
1. Turn the power bank on by pressing the on/off button; after the diodes indicating the battery charge
light up, press the button again to activate wireless charging.
2. Place your mobile device on the wireless charging surface of the power bank marked with a white circle.
3. When wireless charging is in progress, the LED indicator flashes green and blue. White LEDs indicate
the remaining battery status.
4. If the charging function is not working, move the device as needed or remove all obstacles between
the mobile device and the charging surface (such as a resilient phone cover).
Safety instructions
Carefully read the safety and operating instructions below. This will prevent possible damage or damages
to the device. The manufacturer accepts no liability for damage caused by improper use of this device.
1. Keep the power bank out of the reach of children.
2. This power bank is intended for household use only.
3. Be careful not to drop, intentionally or unintentionally break, bend, dent or otherwise deform the
power bank, which could result in malfunction.
4. Do not disassemble or otherwise interfere with the Power Bank. It does not contain any parts, which
could be serviced by the user in the event of a malfunction.
5. Do not expose the power bank to moisture or immerse it in liquids. Do not expose it to dripping or
splashing water. Do not place water containers, such as vases, on the power bank. Only keeping the
power bank dry can guarantee its proper functioning. Store and use the Power Bank at temperatures
between 0 °C-45 °C.
6. Keep magnetic or metal devices such as defibrillators or credit cards away from the wireless charging
surface.
7. Pay close attention to sufficient distance from heat sources. Exposing the power bank to
temperatures above 60 °C could damage it. Do not expose the power bank to direct sunlight. It is
forbidden to place sources of open fire on it, e.g. burning candles.
8. Never throw the power bank into a fire.
9. Do not use or store the power bank near substances / objects that could ignite, that are flammable or
explosive, etc.
10. Do not leave the power bank unattended while it is in operation.
11. It is forbidden to use a damaged power bank or its accessories.
12. Recharge the power bank at least every three months, even when you are not using it.
13. The power bank can become hot during charging and use. Please pay close attention to its possible
extreme heating, which may indicate a problem with the charging circuit of the electronic device.
In this case, disconnect the power bank from the device immediately and contact a qualified
technician. Make sure there is enough free space around the power bank for proper air circulation.
Do not use on a surface covered with cloth (e.g. tablecloth)
14. Never cover the power bank.
15. When fully charged, disconnect the power bank from the power supply to ensure a longer life.
16. Use only a dry cloth for cleaning. It is forbidden to use water, chemicals, solvents, petrol, etc. for
cleaning.
17. Store the power bank in a dry and well-ventilated place, out of reach of children or pets. Do not place
any objects on the power bank during storage.
18. Charging more than one device at a time may reduce the charging power of the power bank.
Exclusion of liability
This external battery has been designed for being used with suitable mobile devices. Prior to first using
the battery with a new device, always verify their mutual compatibility. The manufacturer should not be
responsible for any damages of any mobile device caused by an incorrect use of this product.
This symbol on the product or in the accompanying documentation indicates that the
product must not be considered a regular municipal waste and must be disposed of in
accordance with local regulations. Pass thi product for environmentally safe disposal. Proper
disposal of this product protects the environment. For more information, contact your local
municipal waste disposal office, the nearest collection point or your dealer.
This product complies with all the essential requirements of the EU directives that apply to it.
3 LED: 50-75%
4 LED: 75-100%
USB-C cable
Type: USB-C to USB-A
Length: 0.5 m
Material: PVC
Weight: 14 g
