Serial ATA2 Connectors
(SATA2_4:
see p.1, No. 6)
(SATA2_5:
see p.1, No. 5)
Serial ATA3 Connectors
(SATA3_0:
see p.1, No. 7)
(SATA3_1:
see p.1, No. 8)
USB 2.0 Headers
(9-pin USB4_5)
(see p.1, No. 15)
(9-pin USB6_7)
(see p.1, No. 13)
USB 3.0 Header
(19-pin USB3_2_3)
(see p.1, No. 9)
Front Panel Audio Header
(9-pin HD_AUDIO1)
(see p.1, No. 18)
hese two SATA2
connectors support SATA
data cables for internal
storage devices with up to
3.0 Gb/s data transfer rate.
hese two SATA3
connectors support SATA
data cables for internal
storage devices with up to
6.0 Gb/s data transfer rate.
Besides four USB 2.0 ports
USB_PWR
P-
on the I/O panel, there
P+
GND
DUMMY
are two headers on this
motherboard. Each USB
1
GND
2.0 header can support
P+
P-
USB_PWR two ports.
Besides two USB 3.0 ports
Vbus Vbus
Vbus IntA_PB_SSRX-
on the I/O panel, there
IntA_PA_SSRX- IntA_PB_SSRX+
IntA_PA_SSRX+ GND
is one header on this
GND IntA_PB_SSTX-
IntA_PA_SSTX-
IntA_PB_SSTX+
motherboard. Each USB
IntA_PA_SSTX+ GND
IntA_PB_D-
GND
3.0 header can support
IntA_PA_D- IntA_PB_D+
IntA_PA_D+ Dummy
two ports.
1
his header is for
GND
PRESENCE#
MIC_RET
connecting audio devices
OUT_RET
to the front audio panel.
1
OUT2_L
J_SENSE
OUT2_R
MIC2_R
MIC2_L
H81M-HDS R2.0
11
