with the
icon.
6. Release "SYNC" and the choice is confirmed
CHOOSING THE PRE-PROGRAMMED PERIOD.
1. The 4 pre-programmed periods each have corresponding indicators at the top of
the display to show which programme is selected.
2. To change the programme selected make sure the watch is in timer function with
the timer stopped and the display at zero (by pressing "CLEAR")
3. Press and hold the "SYNC" button in, and then whilst holding it in press "PROG".
Each time "PROG" is pressed the display will change to the next available
programme.
4. The sequence the programmes are available in is 5,4,1,0. Followed by 5 mins,
followed by 3 mins, followed by 1 min. After 1 min the next programme will be
6
(by pressing "PROG" just once for countdown repeat) or multiples of that period
if required (by pressing "PROG" several times for countdown and up or the 1
minute programme of countdown repeat)
2. To change between countdown & up and countdown repeat, press and hold in
the "SYNC" button. Whilst holding this in, press the "CLEAR" button. You will see
the icon
for countdown & up or
3. Once the display shows the correct number of minutes press "START" and the
timer counts down in minutes and seconds towards zero. The display also shows
the icon for countdown repeat
arrow icon
is shown.
4. During countdown the timer can be stopped and restarted as many times as
required.
5. During countdown mode the alarm will sound (if it is on) every minute with an
alarm sequence more often during the last minute.
6. When the timer reaches zero, if you are in countdown and up it starts to count up
and the display shows the up arrow icon
59secs and the start at 0:00 again. This count up will show elapsed race
time and will be particularly useful in handicap racing.
7. If you are in countdown repeat, that icon stays permanently on and the timer
reverts to the programmed time chosen and continues to count back down again.
8
USEFUL HINTS ABOUT WEARING/MOUNTING THE WATCH
1. The watch can be worn just like any normal watch on the wrist. However if the
display is not convenient to look at, then the whole timer case can be turned
inside the outer clip to get a better viewing angle.
2. If you prefer to have the watch on top of the hand, then the timer should be
removed from the outer clip, and the elasticated strap removed from the outer clip.
The outer clip can then be sewed to a
glove using the 2 holes already in the clip.
The timer can then be pushed back into
the outer clip at whatever viewing angle
is required. Take note to make sure the
timer clicks back positively into the outer clip.
3. The outer clip can also be fitted to the
boom or any flat surface by using the
plastic spacer bar provided. This is fitted in
between the boat and the outer clip using
countersunk screws or pop rivets. If this
spacer is not used it will be virtually
impossible to remove the timer from the clip.
10
LOW BATTERY INDICATOR
The timer is equipped with a low battery indicator located in the top left side of the
display. When the indicator is on, it is time to change the battery. It is likely that
the watch will function for several days with the indicator on.
TO CHANGE THE BATTERY
12
for countdown repeat.
or for countdown and up just the down
. The timer will count up to 59mins
FITTED TO BOOM
OUTER CLIP
Note: This may be easier to do if you
pull the elastic strap out of the clip.
5,4,1,0. again and so on.
Note: The programme required will probably stay constant every time you race
at the same club, and will probably only need changing if you race somewhere
else that uses a different starting sequence.
SILENCING THE ALARM
If you prefer to use the watch purely as a visual reference only it is possible to
silence the alarm. This is done by pressing "MODE" and holding it down for
approximately 2 seconds. A short bip indicates
that this has been successful, and the icon of
the bell in the top right of the display disappears
to show the alarm is off.
To re-activate the alarm press and hold "MODE" for 2 seconds until you hear the
bip and the icon of the bell comes on to show that the alarm is on.
USING THE COUNTDOWN FUNCTION
1. Once you have chosen the programme required, and decided whether to have
the alarm on or not, chose whether you want just one period of that programme
THE SYNCHRONIZE FEATURE
You will note that the lower right button is printed "SYNC". This is the synchronize
button. This only has a function during count down and when the timer is running.
Once the timing sequence is started, you may feel that you were late starting your
watch and that consequently your watch is a few seconds late. You may even
have missed the preparatory signal altogether. Do not worry. Instead just start the
watch.
When the next signal is given by the starter, just press "SYNC" and the display will
drop down to the next full minute in countdown. (E.g. if the watch show 5:08,
pressing "SYNC" will send the watch to 5:00 and it will continue to count down.
Likewise if the watch shows 3.35 or even 3.59 and you press "SYNC" the time will
jump to 3:00.) Therefore the "SYNC" button can be used to get your starting
sequence quickly in perfect unison with the official starter.
NOTE: Pressing "SYNC" accidentally would obviously get you out of line with the
official time. All the buttons on the watch are positive click-type buttons to help
avoid them being knocked. To increase this protection the "SYNC" button is fitted
with an even stiffer click button. Therefore your "SYNC" button is tighter than the
other buttons and this is deliberate and for good reason.
ADJUSTING THE ELASTIC STRAP
PLASTIC
SPACER
There is a right way and a wrong way to adjust the elastic strap. Please take note
to avoid any chance of the strap coming undone.
1. Place the watch on the wrist and pass the elastic through the clasp from the
bottom to the top.
2. Pull the elastic to the required tightness and secure by pressing the clasp firmly
closed.
3. Push the elastic loop over the spare length of elastic to keep the loose
end tidy.
1. Remove the timer from the outer clip.
2. Using a cross-point screwdriver carefully remove all 6 screws from the timer, and
remove the case back from the case front to reveal the battery.
3. Remove the old battery and replace it with a new one making sure that the +ve
contact faces upwards. (Avoid holding the battery so that your fingers touch both
the +ve and -ve contacts at the same time).
4. The battery type is a CR2032 3.0 Volt Lithium Battery.
5. Replace the case back making sure that the battery is correctly fitted, that the
rubber seal around the case back is seated properly, and that the case back fits
without interference.
6. Replace the 4 screws taking care not to overtighten them to the point of stripping
the thread.
7. Replace the timer in the outer clip making sure that the timer snaps positively
back into the outer clip.
7
9
11
13
