Product Schematic

LED Display

a
b
c
d
e
LED Display
a Battery Indicators
b Roller Brush Alert Light
c Filter Clog Alert Light
Power Mode Indicators
d
Power Mode Switch
e
1. LED Display
2. Power Switch
3. Handle
4. Charging Port
5. Battery Pack
6. Battery Release Button
7. Main Motor
8. Main Motor Release Button
9. Dust Cup Open Button
10. Dust Cup Release Button
11. Retractable Metal Tube
12. Metal Tube Extending Button
13. Cleaner Head Release Button
14. Motorized Cleaner Head
15. LED Lights
1 2 3
7
8
9
6
10
11
12
13
14
15
