2. Parts list

NO. Description
1 Front plank(Left)
2 Front plank (Right)
3 Main frame plank (Left)
4 Main frame plank (Right)
5 Pedal plank
6 Nether plank
7 Upper plank
8 Sliding wheel stat-or
9 Pedal stat-or assembly
10 Front connection strap
11 Back connection strap
12 One-way axis ribbon weaving
group
13 U-shape ring spacer
14 U-shape ring transparent
pushing
15 hexagon(al) nut M8
16 hexagon(al) lock nut M8
17 Gap tubes
18 Guide wheel group
19 deep groove ball bearing 6203-
2RS
20 circlip for hole Ø40
21 Rubber seal
22 hexagon(al) lock nut M8
(stainless steel)
23 Allen socket full thread screw
M3*30 (stainless steel)
24 Flat washer
25 Water tank fixing plate
26 Silicone gasket
27 Water tank stopper
28 Upper water tank
29 Water tank gasket ring
30 Pan head full thread bolt M8*20
(stainless steel)
Manual – Rower – Senz Sports – R6000 – SZRT003 and SZRT004
R6000
QTY NO.
1 31
1 32
1 33
1 34
1 35
1 36
1 37
1 38
1 39
1 40
1 41
1 42
1 43
2 44
2 45
6 46
2 47
1 48
1 49
1 50
1 51
2 52
12 53
24 54
1 55
1 56
1 57
1 58
2 59
3 60
Description
Plastic fan (POM)
Water tank gasket ring
Nether water tank
hexagon(al) lock nut M3
Transmission belt guide wheel
axis
Deep groove ball bearing 6004zz
Transmission belt guide wheel
Circlip for axis Ø10
Conical feet pad
Allen C.K.S full thread screw
M8*25
Allen C.K.S full thread screw
M8*15
Wheel
Allen C.K.S half thread screw
8*45*20
Bushing Ø12*Ø8.1*12
Allen cylinder full thread screw
M8*110*25
Allen C.K.S half thread screw
M8*110*30
C.K.S half thread screw
M8*40*20
Deep groove ball bearing 6003ZZ
Axis press plate
Philips C.K.S. self-tapping screw
ST4*16
Magnetic induction box
Grip
Handle bar decoration cover left
Handle bar welding group
Handle bar decoration cover right
Console
Console fixing plate
C.K.S. full thread screw M5*10
Spring washer Ø10
Allen C.K.S. full thread screw
M10*20
QTY
1
1
1
12
1
2
1
1
10
16
22
2
4
4
2
1
4
2
1
10
1
2
1
1
1
1
1
4
1
1
4
