help of the wheel (9).
2. Use the height adjuster (8) to adjust the 360
cross line laser to the required height. To dis-
mantle, proceed in reverse order.
Using the tripod (not included) (Fig. B)
1. Place the device with tripod connection (10,
11) on the thread of the tripod or a conventional
camera tripod.
2. Roughly align the tripod before switching on the
device.
4. OPERATION
Only the centre of the laser line must be
used for marking. The width of the laser line
changes depending on the distance.
It's recommended to carry out an accuracy
check before first use and periodic checks
during future use, especially for precise
layouts. Also when the laser may have been
dropped.
Danger of injury due to defective compo-
nents! The product must only be put into
operation if no defects are found. Ensure
that any defective parts are replaced before
the product is used again.
WARNING! Risk of injury due to laser beam!
Never direct the laser beam towards
people, other living creatures or reflecting
surfaces.
Charging the device (Fig. C)
The device must be charged before first
use.
1. Plug the USB type-C plug (14) into the USB
type-C connector (17) on the device.
2. Plug the USB type-A plug (16) into an power
adapter (not included) or device (e.g. computer,
powerbank) with suitable female USB connec-
tor. Please note that the device should be able
to deliver constant 5V 2A power.
3. The Battery LED indicator (4) will lighten up and
show the charging status.
WWW.VONROC.COM
LED Charger status
Red Battery charging in progress
Green Charging finished, battery fully charged
4. After the battery is fully charged remove the
USB type-C plug (14) from the USB type-C con-
nector (17).
It is also possible if the battery is empty to
power the device with the charger or with a
power bank. Follow the steps as above.
When the device is not being used over a
longer period of time it is best to store the
battery in charged condition.
Check the device:
• Make sure all parts are fitted on the machine
firmly.
• Check whether there are any visible defects:
broken parts, cracks, etc.
• Check the accuracy when it is the first time you
are using the laser or when the laser has not
been checked for accuracy in a while.
• Also check the accuracy when the laser may
have been dropped.
Self- levelling mode (Fig. A, D)
The lasers are aligned automatically by the pen-
dulum so that the vertical and horizontal lines are
displayed level on the wall.
1. Place the laser on a flat surface or fit it to the
magnetic bracket (6) or tripod (not included)
and fasten it as described above.
2. Slide the lock switch (2) to the right.
3. The laser lines can be powered one at a time or
all at the same time.
- Press the ON / OFF button (1) on the device
to power on the horizontal line and the front
vertical line.
- Pressing two times the ON/OFF button (2)
for the vertical front laser.
- Pressing three times the ON/OFF button (2)
for the horizontal laser.
4. If the operating mode LED (5) is illuminated in
red and the laser flashes, the permissible incli-
nation range of 6 degrees is exceeded. Position
the device horizontally until the operating mode
LED (5) lights green and the laser stops flashing.
