Left View; Right View - AWOW CreaBook i540 Benutzerhandbuch

Left View

ss
1 2 3
1.DC power adapter jack
2.HDMI port
3.Type-C port
4.USB port
4.Power LED
4.Battery LED
USB Port:
You can connect a USB device to your computer by inserting its
USB plug (Type-A) into the USB port on your computer.

Right View

1.Security Slot
2.Earphone jack
3.LAN port
4.USB port
5.USB port
6.Micro SD card slot
ss
4 5 6
Connects to the DC adapter.
Connects to devices with HDMI input.
Connects to Type-C devices (USB 3.1).
Connects to USB devices (USB 3.1).
Indicates the power status
Indicates the battery status
6
For connecting the Kensington security
lock.
Connects to earphone
Connects network with RJ45 port
Connects to USB devices (USB 3.1).
Connects to USB devices (USB 2.0).
Accepts micro SD card (not supplied).
3
5 4 3 2
ss
