Roebuck RB3331 Bedienungsanleitung Seite 2

Air Diagram:
1/4"NPT
Pad Size Power
Model
1 2
[mm] [w]
[inch] [hp]
150 210
RB3331
6 0.3
3/8" (10mm)
Dimension
Speed
LxWxH
W
L
3 4
[rpm] [mm] [inch]
12000 221x150x105 8.7x6.4x4.1
1/2" (12mm)
LUBRICATOR
Fig. 01
L
Fig. 02
Air Consumption
Weight
At load Average
5 6
[L/min] [l/min]
[Kg] [lb]
[SCFM] [SCFM]
453 227
0.79 1.74
16 8
REGULATOR
90
0 130
A
Inner Sound
Air
Hose Pressure
Inlet
Dia. LpA
7 8
[inch] [mm] [inch] [dB(A)]
1/4 10 3/8 81
1/2" (12mm)
FILTER
Vibrations
Sound
Power
LwA
ahd K
9 10 11
[m/s²] [m/s²]
[dB(A)]
5.13 1.79
92
