Mounting
Before mounting this product, read the
• Fits nicely on a standard 19" rack.
• Can be placed on a flat level surface.
• Has 2 four-directional tear-drop holes on the bottom for hanging on a wall or securing to a surface.
Make sure the mounting hardware is capable of supporting the weight of the product.

Mounting Diagram

Four-
directional
tear-drop
holes
4
QUICK REFERENCE GUIDE
Safety Notes. The LΩGIC Drive 2X:
Mounting surface or wall
