Fractal design DEFINE R4 Benutzerhandbuch Seite 36

9
3
11
2
1.
2.
4.
5.
6.
8.
9.
11.
12.
1
** SSD drives have to be mounted before motherboard is mounted.
In order to be able to secure screws.
Frontpanel
Mounting bracket for fans including
Removable upper hdd cage
Lower hdd cage
hdd mounting bracket
ModuVent
Noise damping material
Fan controller switch
Placement for SSD drives **
Backside of motherboard tray
12
