2.0 Microscope at a Glance

Microscope at a Glance
3 & 4
16 & 17
5 & 6
18
1. Monocular Head
2. Stand
3. Nosepiece
4. Objective Lens
5. Stage Clip
6. Mechanical Stage
7. Condenser Knob
8. Fine Adjustment Knob
9. Coarse Adjustment Knob
10. Light Intensity Adjust
Note: Microscope features may vary based on your location, language,
carrier, and model number. Accessory parts may incur additional fees.
Contact your local distributor to ensure the features.
1
BIMC-12A
11. Power Plug
12. Fuse Box
13. On/Off Switch
14. Viewing adjust
15. Condenser Turning
16. Y-axis movement
17. X-axis movement
18. Light Source Cover
Page 4
14
2
9
8
7 & 15
11, 12 & 13
10
