OPERATING INSTRUCTIONS
DM-20 Vocal Microphone
Item no. 31 45 90
Intended use
The microphone is intended to convert acoustic signals (sound waves) into electrical signals.
The low-level audio output may only be connected to suitable microphone inputs of audio
devices.
The product may only be used indoors, never outdoors. Do not expose the device to damp, e.g.
in bathrooms etc.
Any use other than that described above could lead to damage to this product and involves the
risk of short circuits, fire, electric shock, etc.
The safety instructions must be observed at all times.
Safety Instructions
The warranty will be void in the event of damage caused by failure to observe
these safety instructions. We will not assume liability for any resulting damage.
We shall not accept liability for damage to property or personal injury caused
by incorrect handling or non-compliance with the safety instructions. In such
cases, the warranty will be null and void.
The exclamation mark symbol indicates important information in these opera-
ting instructions. Please read all the instructions before using this device; they
contain important information on its correct operation.
• For safety reasons, any unauthorised conversion and/or modification to the product is not
permitted.
• When connecting the microphone, pay attention to the safety instructions of the device to
which it is to be connected.
• Do not expose the microphone to high temperatures, strong vibrations or drips or water spray.
• Don't leave packaging materials lying around carelessly; they maybe become a dangerous
plaything for children.
• If in doubt about how to connect the product correctly, or should any questions arise that are
not answered in these operating instructions, please contact our technical advisory service or
another specialist.
Getting Started
Connect the product to suitable microphone inputs only in order to prevent
distortions or mismatching that might involve damaging of the microphone or
of connected audio devices. To do this, please pay attention to the connection
data in the „Technical data" section.
Never point the microphone at the speakers in your loudspeakers, since this
may lead to interference, which could damage the loudspeaker and the con-
nected amplifier.
Connection
• Switch off the audio device to which the microphone is to be connected.
• Switch off the microphone, using the ON-OFF switch on the shaft (push downwards).
• Plug the jack plug on the microphone cable into the microphone input socket on your audio
device. If the audio device has a 6.3 mm jack socket, please plug the enclosed adapter on the
connection plug.
Operation
• Switch on the microphone, using the ON-OFF switch on the shaft (push upwards).
• Switch on your audio device.
• Please adapt the sensitivity of your audio device by using the corresponding input level control
for the microphone (see the instructions for the audio device).
Disposal
Electronic devices are recyclable waste materials and must not be disposed of in
the household waste!
Dispose of an unserviceable product in accordance with the relevant statutory
regulations.
Version 01/13
°
Technical Data
Frequency range:
Sensitivity
Guide characteristics
Connecting cable
Frequency response and guide characteristics
These operating instructions are a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com).
All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data
processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited.
These operating instructions represent the technical status at the time of printing. Changes in technology and equipment reserved.
© Copyright 2013 by Conrad Electronic SE.
120-12000 Hz
-60 dB
cardioid
3 m
