CORDLESS PLANER
INTENDED USE
The device is suitable for planing wood in the form of beams or boards or the like if the workpiece is held securely in a fixed
position. The device is also suitable for chamfering edges and for rabbeting.
The equipment is designed for use by adults. Young people under the age of 16 are permitted to use the equipment only under
supervision. The manufacturer shall not be liable for damages caused by use other than for the intended purpose or by
incorrect operation.
DELIVERY SCOPE ( Fig 1)
Dear customer,
Thank you very much for your choosing our products. Please check that the article is complete as specified in the scope of
delivery. If parts are missing, please contact our service center or the sales outlet.
Item No. Item Description
1 Planer Tool body
2 Parallel guide fence
3 Screw knob
4 Screw nut
Danger! The equipment and packaging material are not toys. Do not let children play with plastic bags, foils or small parts.
There is a danger of swallowing or suffocating!

TECHNICAL SPECIFICATIONS

Model
Voltage
Drive wheel speed
Cutting width
Max. Cutting depth
Base size
NOISE/VIBRATION INFORMATION
●
The vibration level given in this information sheet has been measured in accordance with a standardised test given in EN
62841 and may be used to compare one tool with another. It may be used for a preliminary assessment of exposure.
The declared vibration emission level represents the main applications of the tool. However if the tool is used for different
applications, with different accessories or insertion tools or is poorly maintained, the vibration emission may differ. This may
significantly increase the exposure level over the total working period.
An estimation of the level of exposure to vibration should also take into account the times when the tool is switched off or when
it is running but not actually doing the job. This may significantly reduce the exposure level over the total working period.
Identify additional safety measures to protect the operator from the effects of vibration such as: maintain the tool and the
accessories, keep the hands warm, organisation of work patterns.
EXPLANATION OF SYMBOLS
Attention!
Read the manual.
Wear eye protection
Wear breathing protection
Electrical
disposed of with the domestic waste.
PRODUCT ELEMENTS (Fig. 2)
1 Switch interlock knob
2 Dust port shift knob
3 Screw knob
4 L-bracket
5 Bolt
6 Screw nut
Quantity
1
1
2
1
CEP-S20Li (WT6012)
20Vd.c.
15000 /min
82mm
2mm
79x284mm
appliances must not
9
10
11
12
13
14
Item No. Item Description
5 Bolt
6 L-bracket
7 Spanner & hex wrench
Rabbet cutting depth Max.
Recommended battery
Sound pressure level
Sound power level
Vibration emission
Weight (without battery)
Disassemble the battery pack before maintenance.
Wear working gloves.
Wear ear protection
Compliance with the relevant requirements of EU
directives).
be Do not use the machine in the rain or eave it
outdoors when it is raining.
Left dust exhaust port
Spanner compartment
Belt cover
Parallel guide fence
Cutting depth adjustment knob
Right dust exhaust
Quantity
1
1
1+1
12mm
CLB-20V-4.0/ CLB-20V-4.0H
LpA=84dB(A), K=3 dB(A)
LwA=95dB(A), K=3 dB(A)
2
ah=5,22m/s ,K=1,5m/s
2.5kg
17 Screw knob
18 Rear footpate
19 Cutting drum assy.
20 Blade
21 Locking nut
22 Chamfering groove
2
