Product specifications:
CM100GLTE
Model Name
Color/Size/Weight
LTE Module
LTE Supported Band
LTE Features
LTE Transmit Power
USIM Interface
GNSS Feature
Connector Type
USB Interface
LTE Antenna Type
GNSS Antenna Type Ceramic Patch Antenna
Power Supply
CM100GLTE
Black / Length 90 mm x Width 60 mm x Height 10 mm / 110g
Quectel EC25
EC25-A : B2/B4/B12
EC25-J : B1/B3/B8/B18/B19/B26
EC25-E : B1/B3/B5/B7/B8/B20
Support up to Non-CA CAT. 4 FDD
Support 1.4/3/5/10/15/20MHz RF Bandwidth
LTE-FDD : Max 150Mbps(DL) / Max 50Mbps(UL)
Class 3 : 23dBm +/-2dBm @ LTE-FDD Bands
Support USIM Nano Card / 3.0V
Gen8C Lite of Qualcomm
Protocol : NMEA 0183
Mode : GPS L1, Glonass G1, Galileo E1, Bei-dou B1
Micro USB Type-B Connector with Harness Cable
Compliant with USB 2.0 specification(Slave Only), Reach up to
480Mbps for data transfer rate
Fixed / Intenna (Main, Diversity)
USB Harness Cable : 3.0m
Typical Supply Voltage : 5.0V / 1A
Supply Input Voltage : 3.3V ~ 5.5V / Max. Current : 2A
7
