ASHDOWN ENGINEERING - THE NEWT
SPECIFICATIONS:
Inputs
High Input
Low Input
Effects Return
Line Input
Outputs
Effects Send
D.I.Output
Speaker Outputs
Frequency Response
Headphone Output
Equalisation
Bass
Middle
Treble
Shape
Signal to Noise
Distortion
Output Power
Impedance - 3.9M ohms
Impedance - 10k ohms
Impedance - 22k ohms
Impedance - 22k ohms
Impedance - 22k ohms
420 ohms balanced
Minimum Impedance - 4 ohms
-3db at 22hz and 25khz
3.5mm Jack output @ 32Ohms
+/- 15db @ 100hz
+/- 15db @ 660hz
+/- 15db @ 7khz shelving
+ 8db @ 50hz + 10db @ 10khz
Better than 80db (E.Q. Flat)
Less than 0.5% Thd
200watts into 4 ohms
Input range 150mv to 20v p - p
Input range 300mv to 40v p - p
Input level 0dbu nominal
Input range 300mV
Level 0dbu nominal
pre ground lift Level -20dbu nominal
USER GUIDE
