EN Peel off the foil on the other side of the sticker. To apply, press the sticker onto the surface for 10 seconds. Ensure the anti-skid layer on the camera's feet is clean and
free of dust. Place the camera onto the metal disc with magnetic feet facing down. FR Enlever l'aluminium sur l'autre côté de l'autocollant. Pour fixer l'autocollant, appuyer
sur celui-ci en maintenant une pression uniforme pendant 10 secondes. S'assurer que la couche antidérapante sous les pieds de la caméra est propre et exempte de
poussière. Placer la caméra sur le disque de métal en assurant que les pieds magnétiques sont positionnés à plat sur ce dernier. DE Ziehen Sie die Folie auf der anderen
Seite des Aufklebers ab. Zur Montage drücken Sie den Aufkleber 10 Sekunden lang auf die Oberfläche. Vergewissern Sie sich, dass die Anti-Rutsch-Schicht auf den Füßen
der Kamera sauber und staubfrei ist. Positionieren Sie die Kamera mit den magnetischen Füßen auf der Metallscheibe. ES Retire la lámina del otro lado del adhesivo.
Para aplicar, presione el adhesivo sobre la superficie durante 10 segundos. Asegúrese de que la capa antideslizante de las patas de la cámara esté limpia y libre de polvo.
Coloque la cámara sobre el disco de metal con las patas magnéticas hacia abajo. PT Retire a folha do outro lado do adesivo. Para aplicar, pressione o adesivo na superfície
durante 10 segundos. Certifique-se de que a camada antiderrapante das pernas da câmara está limpa e sem pó. Coloque a câmara no disco metálico com as pernas de
magneto viradas para baixo. NL Verwijder de folie aan de andere kant van de sticker. Druk de schijf met sticker gedurende 10 seconden op het oppervlak om deze aan te
brengen. Zorg ervoor dat de antisliplaag op de voetjes van de camera schoon en stofvrij is. Plaats de camera op de metalen schijf met de magnetische voetjes naar beneden.
3
EN Check the camera image in the mobile app as you position the camera body. Hold down the camera's feet as you angle and rotate the camera body. RECOMMENDED:
Position the camera as close to the network router as possible for optimal functionality. FR Vérifier l'image de la caméra dans l'appli mobile pendant le positionnement
du boîtier de la caméra. Tenir les pieds de la caméra pour incliner ou faire pivoter le boîtier de la caméra. RECOMMANDÉ : Positionner la caméra aussi près que possible
du routeur de réseaux pour un fonctionnement optimal. DE Überprüfen Sie das Kamerabild in der App, während Sie die Kamera positionieren. Drücken Sie auf die Füße
der Kamera, während Sie die Kamera schwenken und drehen. EMPFEHLUNG: Positionieren Sie die Kamera so nah wie möglich am Netzwerkrouter, um eine optimale
Funktionalität zu gewährleisten. ES Compruebe la imagen de la cámara en la aplicación móvil mientras coloca el cuerpo de la cámara. Mantenga presionadas las patas de
la cámara mientras inclina y gira el cuerpo de la cámara. RECOMENDADO: Coloque la cámara lo más cerca posible del router de red para una funcionalidad óptima. PT
Verifique a imagem da câmara na aplicação móvel enquanto coloca o corpo da câmara. Pressione e segure as pernas da câmara enquanto inclina e roda o corpo da câmara.
RECOMENDADO: Coloque a câmara o mais próximo possível do router de rede para obter uma funcionalidade ótima. NL Controleer het camerabeeld in de mobiele app
terwijl u de camerabehuizing positioneert. Houd de voetjes van de camera ingedrukt terwijl u de camerabehuizing draait en kantelt. AANBEVOLEN: Plaats de camera zo
dicht mogelijk bij de netwerkrouter voor optimale functionaliteit.
14
WI-FI & APP / WI-FI ET APPLI / WIFI & APP / WI-FI Y APLICACIÓN / WI-FI E APP / WIFI & APP
EN
PLEASE VISIT HTTPS://WWW.CATIT.COM/HELP-ADVICE/
FOR THE LATEST INFORMATION AND GUIDES.
Quick setup
1. Scan this QR code and download the app, which is available in the App
Store and on Google Play. Click "Sign up" to get walked through creating
your account.
2. Plug the camera's adapter into an electrical socket
so the device becomes operational.
Check if the Wi-Fi LED on the back of the device is blinking slowly,
indicating the device is ready to connect to Wi-Fi. (If not, see
'Troubleshooting' below.) Open the App and click the + button to get
walked through the Setup steps.
Wi-Fi LED guide (located on the back of the camera body):
• Blinking blue (slowly): Ready to connect to Wi-Fi
• Blinking blue (quickly): Wi-Fi connection not established
• Steady blue: Connected to Wi-Fi
Troubleshooting:
• The camera doesn't support 5 GHz Wi-Fi, please make sure your Wi-Fi is 2.4 GHz.
• If the Wi-Fi LED is not blinking after the camera is switched on, use a pen to
press the reset button at the bottom of the device and hold it for 5 seconds
until the Wi-Fi LED starts blinking.
• If the Wi-Fi LED is blinking quickly, this could be for a number of reasons: 1. The
device is connected to the router, but there's no internet. 2. The device is trying
to connect to the router, but not succesful yet. 3. The device is disconnected
from the router.
• If you have trouble establishing a Wi-Fi connection or are experiencing video
streaming issues, check that you are within range of the Wi-Fi signal and there
aren't too many obstructions (such as walls) weakening the Wi-Fi signal strength.
TM
There are two ways for the Catit
PIXI
Smart Mouse Camera to connect to
®
your Wi-Fi / Wireless router:
• QR code (default): The mobile app will ask you to provide your wireless router
info (SSID and password). The app will then generate a QR code containing
this information, which you need to scan using the camera. The camera
uses this information to automatically connect to your Wi-Fi network. If you
have difficulties scanning the QR code, try again or use AP mode to connect
(see below).
• AP mode (can be selected at the beginning of the connection procedure):
Select the PIXI
Smart Mouse Camera's signal from your mobile phone's Wi-Fi /
TM
WLAN list. The camera will be listed as "SmartLife-XXXX". Once the connection is
established, the app can connect to the PIXI
TM
Smart Mouse Camera and transfer
your wireless router info (SSID and password). The camera uses this information
to automatically connect to your Wi-Fi network.
With the mobile app, the following features can be controlled remotely
(Please ensure you have the latest app version installed):
• Watch live: Watch a live stream of the camera's field of view.
• Digital Zoom: Pinch the image to zoom in or zoom out.
• Take photos / make video recordings: Save captured images/video to your
smartphone's camera roll. To record and save video automatically (by motion-
detection), continuously, or with a timer, an additional micro-SD card is required
(max. 256GB, not included).
• Selective motion-detection: Select areas in the camera's field of view that will
trigger a notification and automatic recording when motion is registered
• Two-way audio: Listen and talk to your cat through the camera's built-in mic
and speaker.
• Night vision: Option to automatically switch to infrared imagery in low light
conditions (can be enabled/disabled in the app).
• Video playback: Watch previously recorded video (Micro-SD card required,
max. 256GB).
• SD/HD: Option to switch between SD and HD image/video. SD is the
default setting.
• Notifications: Receive smartphone notifications when motion is detected in
the marked areas.
• Connect to Catit
PIXI
Smart devices: The camera can be connected to
®
TM
other Catit
PIXI
Smart devices to keep watching as you control the other
®
TM
device in the app.
• (Shared) Connection: It's possible to connect multiple PIXI
Smart Mouse
TM
Cameras to your account and give each of them a unique name. You can also
share the device with other accounts (e.g. family, cat sitter) so they can control
and monitor it for you.
For a complete overview and guide on how to use the app features, please
visit https://www.catit.com/help-advice/
(OPTIONAL) To connect the Catit
PIXI
Smart Mouse Camera to other
®
TM
Catit
PIXI
Smart devices: Open the Catit
®
TM
®
PIXI
TM
app on your smartphone,
and select the Catit
PIXI
Smart device you want to connect the camera to.
®
TM
Open the settings menu, tap on 'Connect to Camera' and select the camera. If
successful, a camera icon will be added to that particular PIXI
TM
Smart device in
your app Home screen.
15
