- Adjusting the vertical angle of the speaker -

1
Loosen the vertical angle adjustment bolt at the bottom
of the speaker.
2
Adjust the speaker to the desired angle.
Caution
･ Be careful not to knock over the speaker stand when
adjusting the angle.
･ The speaker will not move sideways.
Tip
The angle of the speaker can be adjusted within the
range of +20° to -10°.
3
Tighten the vertical angle adjustment bolt.
Caution
Securely tighten the vertical angle adjustment bolt.
Speaker
+20°
-10°
−1−
Angle adjustment bolt
Allen key (small)
(included with speaker)
Speaker stand
