Linea Deco ROMANE Montageanleitung Seite 3

C10
729x470x16 mm
729x470x16 mm
C12
662x250x16 mm
355x303x3 mm
Ø7x44 mm
Ø15x12 mm
TM x20 MS x20
Ø15 mm
350 mm
SG x6
PR x3
x1
C9
x1
x1
x3
C6
Ø17 mm
ZM x12
Ø3,5x15 mm
EM x18
C11
729x470x16 mm
x1
C13
677x358x3 mm
Ø8x30 mm
KK x28
Ø1,4x25 mm
Ø3,5x20 mm
EN x18
!
3-12
x1
330x469x16 mm
C7
x3
322x167x16 mm
C8
x3
350x104x16 mm
C5
x3
350x104x16 mm
x3
C4
273x104x16 mm
Ø7x50 mm
KdK x1 KF x10
G x50
C3
x2
Ø12 mm
Z x3
