11D. White cloth
12. Polyester brush 60mm
13.Polyester brush 32.6mm

14. Steam nozzle

•
anti-limescale bottle
•
Funnel D.10 Cm
HOW CAN I HELP YOU DO CHORES?
THESE ARE MY FUNCTIONS:
VACUUM
STEAM
STEAM + VACUUM
ACCESSORIES
VACUM WITH WATER FILTER
- Extract the tank from its seat.( FIG.5)
- Unhook the cover (FIG.6)
- Insert water in the recovery basket until reaching the LEVEL MIN.(FIG.7)
- Hook the cover. (FIG.8)
- Insert the tank in the machine. (FIG.9)
- Insert the plug in the appropriate socket (FIG.10)
- Insert the hose (FIG.11)
- Set the desired vacuum with the specific motor button and hold it down for around 1 sec. to
start the motor (FIG.12)
- By pressing the button 1 time speed 1 is set, press 2 times to set speed 2 and 3 times to set
speed 3.
- Pay attention to the water level in the recovery tank: when the water reaches the maximum
level, the vacuum motor noise changes in intensity, a red "basket full" indicator led goes on
with relative acoustic error signal and the machine does not vacuum. In this situation:
•
Extract the tank
•
Remove the tank vacuum tubes for cleaning and empty it making sure to restore the
minimum level (FIG.13)
•
Carefully rinse the tank and components under running water (FIG.14)
•
Correctly reposition the components in the tank in their respective housing seats
FIG.1
FIG.2
FIG.3
FIG.4
