TUNER ST-2
GUITAR / BASS / VIOLIN / UKULELE
Thank you for purchasing the Klang Tuner ST-2 Guitar / Bass / Violin / Ukulele.
Please read this manual carefully before using the product, and operate it in
accordance with this manual. Please save this manual for future reference.
SAFETY INSTRUCTIONS
• The device is not a toy. Keep it out of the reach of children and pets.
• If you have questions which remain unanswered by these operating
instructions, contact us or other technical personnel.
• For cleaning all you need is a dry, soft and clean cloth.
• Do not use any aggressive cleaning agents, rubbing alcohol or other
inflammable, chemical solutions.
• Do not apply excessive force to the switches or controls.
BATTERY USE
• Make sure the polarity is correct when putting in a new battery.
• Remove the battery when the unit is not in use for a longer period of time.
• If the device is not working correctly, remove the battery and put it back in
after 10 seconds.
• Replace the battery if the LCD light becomes weak or unclear.
• Dispose of the old battery properly.
CONTROLS AND DISPLAY
Accuracy
indication lights
Display screen
Tuning mode
Output
OPERATION GUIDE
Insert the batteries into the back of the device. After turning it on, the device will
be calibrated at A4 = 440 Hz.
1: Button functions
a) Power on/off: Press button 1 "On/Off" to turn the tuner on or off. The display
and the LEDs will be lit and the device will be in tuning mode.
b) If no signal is detected for 3 minutes, the device will turn itself off.
c) The tuning mode can be changed successively by pressing button 2 "Mode":
chromatic, guitar, bass, violin, ukulele. Note: Flat tunings are not available in
chromatic mode.
2: Tuning
a) Place the tuner's microphone (MIC) close to the instrument so you can easily
read the display. Connect your electrically amplified instruments using a
6.3 mm (1/4") jack cable to the input to achieve better results.
b) Select the tuning mode or instrument you want to tune using button 2.
c) Play the string you want to get in tune. The tuner recognizes the note
automatically and shows it in the display.
d) Make sure the right string is shown in the display. For example, if the b
string, i.e. the second string is played in guitar mode, but "1E" is shown
in the display, the string is too high and has to be tuned down. If "3G" is
displayed, it is too low and has to be tuned up.
e) Once the tuner recognizes a tone, it will be shown in the display with its
name and string number. If the pitch needle is left of the middle, the pitch
is too low and a "b" will be displayed next to the note. If the pitch needle is
right of the middle, the pitch is too high and a "#" will be displayed next to
the note. Once the correct pitch is reached and the indication needle is in
the middle, the display color will turn green.
f) After tuning all the strings, check each string's tuning again, as the strings
can influence eachother's tuning.
3: Change reference tone
By pushing button 3 "A4", you can change the reference tone incrementally
from A = 430 Hz to A = 450 Hz.
TECHNICAL DATA
• Tuning modes: Chromatic, Guitar, Bass, Violin, Ukulele
• Tuning range: B0 – B7
• A4 calibration: 430 Hz – 450 Hz
• Transposition: b, bb
• Tuning via internal microphone or input
• Tuning tolerance: ± 1 cent
• Includes: 1 x ST-2, 2 x AAA batteries, manual
DISCLAIMER
Technical specifications and appearance are subject to change without notice.
INFORMATION OBLIGATION FOR THE DISPOSAL OF BATTERIES
According to § 12 par. 1 No. 1-3 BattV (Regulation for the return and disposal
of used batteries and accumulators (BattVO) dated March 27, 1998 (BGBl. I
S. 658)) we as seller inform that the customer as end consumer is obliged to
return used batteries by law. Batteries can be returned free of charge after use
to the seller or to his waste disposal centre in his direct vicinity. If batteries are
sent to the seller, sufficient postage is to be paid. The the symbol of the wheel
bin means that the batteries contain heavy metals and harmful chemicals that
may not be disposed of in household or commercial waste. The abbreviations
under the symbol mean: "Cd" (Cadmium), "Pb" (Lead), "Hg" (Mercury)
DISPOSAL ADVICE FOR EEE-ARTICLES
Our customer is obliged to return the EEE-article after its lifespan separately
from the household or commercial waste. EEE-articles can be returned free of
charge after use to the seller or to his waste disposal centre in his direct vicinity.
session GmbH & Co. KG, Wiesenstraße 2-6, 69190 Walldorf, info@session.de
WEEE-Nr.: DE 14977334
Button 1
On/Off
Button 2
Mode
Button 3
A4
Input
