Seite 8
Item Menu Explain Addr A001---A512 address code CHnd 16CH/18 channel CH selection Operation mode selection SLnd (DMX self-propelled voice control slave) SenS Voice control sensitivity adjustment (0-99) ON, OFF screen always on setting DISP YES, NO display forward and reverse settings YES, NO Motor X forward and reverse settings Tilt YES, NO Motor Y forward and reverse settings...
Seite 9
16 CH 18 CH Features Description value X axis 0-255 X-axis fine 0-255 adjustment Y axis 0-255 Y-axis fine 0-255 adjustment X Y axis speed 0-255 Speed from fast to slow Dyeing total Linear dimming from 0-255 dimming dark to bright No function Dyeing strobe Synchronous strobe...
Seite 10
0-127 0-360 degree positioning The motor rotates clockwise from 128-191 Rotating slow to fast 14 16 motor The motor rotates counterclockwise 192-255 from slow to fast 0-29 Channel 1 to channel 13 are valid Macro 40-149 Self-propelled 15 17 function 150-255 Light body sound control 0-240 No function...
Seite 14
! VORSICHT ÖFFNEN SIE DAS GEHÄUSE NICHT STROMSCHLAGGEFAHR Bitte lesen Sie dieses Handbuch sorgfältig durch, bevor Sie dieses Produkt in Betrieb nehmen. — 2 —...
Seite 19
Artikel Speisekarte Instruktion Addr A001---A512 Adressnummer CHnd 16CH/18 Kanal CH Auswahl Betriebsartenwahl (DMX-Selbstfahr- SLnd Sprachsteuerungssklave) Empfindlichkeitseinstellung der SenS Sprachsteuerung (0-99) EIN, AUS Bildschirm immer auf Einstellung JA, KEINE Vorwärts- und DISP Rückwärtseinstellungen anzeigen JA, KEINE Vorwärts- und Rückwärtseinstellungen von Motor X JA, KEINE Vorwärts- und Tilt Rückwärtseinstellungen von Motor Y...
Zurücksetzen des Systems Funktionen Beschreibung Kanäle Kanäle Wert X-Achse 0-255 X-Achsen- 0-255 Feineinstellung Y-achse 0-255 Y-Achsen- 0-255 Feinjustierung Geschwindigkeit Geschwindigkeit von 0-255 der X-Y-Achse schnell bis langsam Totaldimmung Lineare Dimmung von 0-255 färben dunkel nach hell Keine Funktion Synchrone Farbstreifer 10-255 Stroboskopgeschwindigkeit von langsam bis schnell...
Seite 21
0-127 0-360 Dripostionen Der Motor dreht sich im 128-191 Uhrzeigersinn von langsam zu Rotatin 14 16 schnell Moto Der Motor dreht sich gegen 192-255 den Uhrzeigersinn von langsam zu schnell Kanal 1 bis Kanal 13 sind 0-29 gültig Makro 15 17 40-149 Mit Selbstantrieb funktion...
