XMax V3 PRO Bedienungsanleitung

INSTRUCTION
MANUAL
SHARE THE VIEW:
Take a video using the
product with #XMAX
and we will share it with
our global family.
@XMAXVAPORIZER
@XMAXVAPORIZER.CN
BATTERY HEALTH NOTE
PLEASE DO NOT PUT THIS PRODUCT
AWAY OR LEAVE IT FOR EXTENDED
PERIODS OF TIME WITH A LOW
CHARGE. IF THE BATTERY FALLS
BELOW 2% AND IS LEFT THAT WAY
THEN IT WILL NO LONGER ACCEPT A
CHARGE.
birth defects or other reproductive
toxicity. The vaporized aerosol of
chemicals are known to cause
respiratory or other diseases and in
some cases are irreversible. If needed
contact your local poison control center,
USA: AAPCC 1-800-222-1222.
Note that the XMAX V3 PRO is not a
medical device and is not intended to
administer medicinal or illegal
substances of any kind, diagnose, cure,
treat or prevent any diseases or other
conditions.
Any illegal use of this device could
subject the user to severe fines,
penalties and/or imprisonment under
the law of their (and/or other)
jurisdictions.
THIS PRODUCT DOES NOT
CONTAIN ANY BOTANICAL
MATERIAL.
XMAX V3 PRO CONTENTS
SPECIFICATIONS
Battery Capacity
Charging Voltage/Current
Working Voltage
On/Off
Temperature Range
Oven Material
Display Screen
Session Time
On-demand Single
Holding Time
Size
Botanical flower:
Loosely pack the ground substance in
the oven chamber, do not let the
substance beyond the top of the oven
chamber.
Botanical Concentrate:
Insert the concentrate/wax cup
into the oven chamber, use the
dab/scraping tool to load the
desire substance into the cup.
Do not over load the cup chamber.
The recommended fill is approximate
half of the cup capacity's area.
3. POWER ON/OFF
Click power button 3 times, the XMAX
V3 PRO will be powered on and begin to
6
indicates readiness and the timer
countdown starts. Inhale through the
mouthpiece, this device will
automatically begin vaping.
ON DEMAND Mode: Keep holding the
power button for less than 30 seconds
once while inhaling.
5. TEMPERATURE SETTINGS
Press or hold the "up
button" to increase
temperature, press or
hold the "down button"
to decrease
temperature.
6:00
Click to change by
degree, hold to change
quickly.
(5)
Temperature Range：
100℃-220℃（212℉-428℉）
6. TIMER SWITCHOVER
XMAX V3 PRO has 2 session timers, 4
minutes and 6 minutes.
8
simultaneously once. Keep holding the
"power button" for less than 30
seconds once while inhaling when
under "ON DEMAND" Mode.
The device will
automatically power
off if not being used
within 120 seconds.
Click the "up button"
6:00
220
and "down button"
simultaneously once,
then switchover to
220
"SESSION" mode.
(8)
9. OLED DISPLAY
Ba�ery level
Session
220
Target
temperature
6:00
Hea�ng
Current
220
temperature
(9)
10
For deep clean, immerse all pieces
except plastic mouthpiece in isopropyl
alcohol for 10-20 minutes, rinse
thoroughly with clean water and dry
before reassembling.
Stainless steel oven cleaning: use brush
to sweep inside and cotton swab dipped
in isopropyl alcohol.
(10-2)
* Tip: Perform a burnoff cycle at max
temp for 2 minutes after cleaning.
After using the XMAX V3 PRO or
charging, please allow the device to cool
down before storage. It should be stored
in a clean, dry place protected against
the effects of weather and out of the
reach of children and pets. If you have
any concerns or if there is any problem,
12
SAFETY
Prior to your first use, please read and
fully understand the instructions
including the safety information. We
recommend that these instructions be
kept for future reference. Failure to
follow warnings may result in a safety
hazard including electric shock, fire,
property damage, bodily injury or death.
AGE
You must be of legal age in your
jurisdiction to purchase or use the XMAX
V3 PRO. For adult use only.
USE
Never use the product before reviewing
the manual in its entirety. If any section
or topic is unclear prior to use, please
contact customer service for clarifica-
tion.
This product should not be used by
children, women who are pregnant or
breast feeding, or those with life
threatening illnesses without first
14
All batteries may explode or burst into
flame if used improperly or mistreated.
Do not disassemble, puncture tamper,
cut, crush, short-circuit, incinerate or
expose to water, fire or high temperature
above 60°C or 140°F. It is your
responsibility to understand the dangers
as well as the proper procedures for
handling all batteries. Do not dispose of
in trash containers nor litter the
environment.
Please recycle or dispose according to
local safety regulations law. (Suggested
to cover terminals with proper insulating
tape before disposal.)
WARNING
THIS PRODUCT IS NOT INTENDED FOR
NICOTINE. PRODUCT IS DESIGNED FOR
LEGAL BOTANICALS AND
CONCENTRATE USE ONLY. PRODUCT
DOES NOT CONTAIN ANY BOTANICALS
OR CONCENTRATE MATERIALS. KEEP
DEVICE AWAY FROM CHILDREN AND
PETS.
16
cosmetic damage including but not
limited to dents, scratches/chips to
finish, and/ or broken plastic parts.
Normal product wear and tear is not
covered under warranty. Normal
performance degradation of batteries
is also not covered by the warranty.
To make a warranty claim, please
contact customer support at
support@topgreencig.com. The original
bill of sale, authenticity code, pictures or
videos, and any serial numbers are
required to redeem the warranty.
At the manufacturer's discretion,
warranty service will be provided by
repair of the product or exchange of the
product and/or part with a new or
functionally equivalent product/part.
18
2
18650 3.7V 2600mAh
5V/ 1A
3.2-4.2V
Click the button 3 times
consecutively
100℃-220℃（212℉-428℉）
Stainless Steel
OLED
4 minutes/6 minutes
30s
26.6* 23.8*150.2mm
(1.05*0.94*5.91inch)
4
(2-1)
(2-2)
Ba�ery level
ON DEMAND
6:00
220
Target
temperature
Hea�ng
Current
220
temperature
(10-3)
DISCLAIMER
Thank you for purchasing the XMAX V3
PRO. To ensure the best experience,
please read and understand the
instructions fully before your first use
of the XMAX V3 PRO. We strongly
recommend you keep these
instructions for future reference.
We hope you enjoy the excellent quality
and performance of your new XMAX
V3 PRO.
User must be of legal age within any
given jurisdiction to purchase or use
the XMAX V3 PRO, use this product in
moderation. This product should not be
used by a child, while driving or
operating heavy machinery, minors, or
women who are pregnant and/or
breast feeding and those with life
threatening illnesses without first
consulting a doctor.
California Prop 65 WARNING: This
product contains chemicals known by
the state of california to cause cancer
XMAX V3 PRO OVERVIEW
Filter
Component
Power Button
OLED Display
Up Button
Down Button
USB-C Port
3
OPERATION GUIDE
Notice: Please remove protection tab
in battery compartment before using.
1. CHARGE
(1)
Fully charge device before first use.
Please use the provided USB-C cable to
charge your device.
The display screen will show charging,
and be always on when fully charged.
2. LOAD
How to use the oven:
Remove the magnetic mouthpiece lid
and choose which botanical substance
is best for you. Due to the oven's
delicate technology, please be gentle
when packing the oven and/or inserting
the oven cup and / or cleaning.
5
heat up under the default
settings or your last temperature
setting.
Under "ON DEMAND" mode, the
device will automatically become
"STANDBY" Mode if not being
used within 30 seconds. Then it
will automatically power off if not
being used within the next 120
seconds.
Click the power button 3 times to
(3)
turn off and the XMAX V3 PRO
will vibrate to indicate shut down.
4. ENJOY XMAX V3 PRO
Two Modes available While heating, the
OLED display temperature will go
up, " " will flash as well.
ESSION Mode: The device vibration
(4)
7
4:00 6:00
220 220
6:00
220 220
(6)
7. FAHRENHEIT AND
CELSIUS SWITCHOVER
To switchover to
fahrenheit, hold
the "power
button" and
"down button"
at the same
6:00
time for 2
seconds.
8. MODE SWITCHOVER
To switchover to "ON DEMAND" mode,
click the "up button" and "down button"
9
10. CLEANING & MAINTENANCE
To keep the XMAX V3 PRO working
optimally and maintaining the purest
taste, we recommend that all parts
which come in contact with material or
vapor be cleaned regularly.
All removable parts can be
disassembled for optimal cleaning.
Mouthpiece & filter
Gently pull the mouthpiece to remove it.
It can be cleaned with soap and water.
Mouthpiece Tip
Ceramic Air-Path
Holding Silicone
(10)
(10-1)
11
please switch off the XMAX V3 PRO
and/or remove it from the charger
immediately. Do not try to remedy any
defect yourself. Contact our customer
service directly at
support@topgreencig.com.
NOTE:
DO NOT TOUCH THE HEATING
ELEMENT IMMEDIATELY AFTER USE.
DO NOT CLEAN THE WHOLE DEVICE
WITH WATER OR SUBMERGE.
DO NOT INJECT ANY LIQUID OR OIL
INTO THE STAINLESS STEEL OVEN.
MAKE SURE TO DEACTIVATE THE
DEVICE BY LOCKING. MAKE SURE IT
HAS NOT BEEN USED FOR AT LEAST
30 MINUTES AND IS COMPLETELY
COOLED OFF.
WARNING:
HOT COMPONENTS
13
consulting a doctor. It is recommended
that all users consult a doctor prior to
use with your chosen herb or
concentrate. Note that the XMAX V3
PRO is not a medical device and is not
intended to diagnose, cure, treat, or
prevent any diseases or other medical
conditions. XMAX V3 PRO is not
intended to administer medicinal or
illegal substances of any kind. Any illegal
use of this device could subject the user
to severe fines, penalties, and/or
imprisonment under the laws of your
local jurisdiction.
DAMAGE
Immediately discontinue use of the
product if the vaporizer unit is damaged
in any way including but not limited to:
dents, overheating, unusually restrictive
airflow, and/or electrical malfunctions.
Do not attempt to repair product by
disassembly of non-replaceable parts
except mouthpiece, Filter, Packing Tool,
and Removable Battery. Please contact
customer service for help with any
damaged unit.
15
LIMITED WARRANTY
The product is warranted for a period of
12 months from purchase with receipt，
or 12 months from date of manufacture
without receipt against defects in
manufacturing, workmanship, and
materials. This device is designed for the
use of legal herb and concentrates only.
Any use of the XMAX V3 PRO with illegal
substances will void the warranty.
This warranty covers only the electronic
base. This warranty does not warrant
mouthpiece, battery cell, scraping tool
and or other detachable parts. The
warranty does not apply to damage
caused by accident, abuse, misuse,
natural disaster, user error, or use
outside the intended use described in
the manual. Use outside the intended
use as described in this manual also
includes any tampering with device in
any way, including but not limited to
modification to alter functionality，or
modification to alter appearance.
The warranty also does not apply to
17
CUSTOMER SUPPORT
For any question or concerns with the
product, its use or defects, please
contact customer support at
support@topgreencig.com. We will do
our best to provide a response within
two (2) business days after receipt of
written notice.
19
1
Mouthpiece Tip
Scraping tool
Air Hole
Battery Lid
18650 Battery
To switchover
the 4 minutes
and 6 minutes,
just hold the
"power button
and "up button"
at the same time
for 2 seconds.
240
6:00
220 428
220 428
(7)
Filter Component
