Panel Instruction & Basic Operation
EN

Top Panel

7
LED Button:
01
Press and hold this button to activate Tap Tempo.
DRUM/TUNER
Button:
Press the button to switch between 3 Drum items.
02
Rotate the knob to adjust Drum parameters.Hold the button to enter tuner.
Channel Switch:
03
GAIN Knob: Adjust the gain of the DRIVE effects.
04
TONE Knob: Adjust the brightness of the sound.
05
EFFECTS Knob: Select DSP effects (between Chorus/Tremolo/
06
Reverb) and adjust modulation rate or reverb level (turn clockwise to increase).
VOLUME Knob: Control the output volume.
07
Display: Instruct the information of Drum Rhythm or tuner.
08
INPUT
Jack:
1/4" mono audio jack.
09
AUX
In Jack: 1/8" stereo audio jack
10
3 4
6 5
Press this button to start/stop the drum machine.
Select channels between Clean/Overdrive/Distortion/Metal.
8 2
10
1
9
