moisture. Do not reinsert boards until
fabric is completely dry. Always assemble
mattress pad with foam pad on top of
board, and place both fully inside mattress
pad cover.

Parts list

A Bassinet
B Mattress Pad
C Mattress Board
D Foam Pad
E Bassinet Legs
F Carry Bag
Travel Bassinet
See images 1 - 5
1. Pull up on end rails to open bassinet.
2. Push the center down until locked
securely into place.
3. CHECK all 10 snaps are fastened before
using bassinet.
4. If not in place, insert mattress pad soft
side up into bassinet.
To Assemble Travel
Bassinet Legs
See images 6 - 11
1. Flip bassinet upside down, and attach
bassinet legs as shown . MAKE SURE
6
basket is not twisted.
2. CHECK that 4 legs are assembled by
pulling on them.
3. Attach 3 snaps on short side of basket
by wrapping snaps around bar on
bassinet. Repeat on other side.
4. Flip bassinet over and open.
5. If not in place, insert mattress pad soft
side up into bassinet.
To Fold Travel Bassinet
See images
12 13
1. Pull up on one of the yellow rings
located on bottom side of bassinet. Pro
Tip: If you're having trouble folding, try
placing a foot on the bottom of the
bassinet to help hold it in place.
2. Fold bassinet as shown
13 .
To Remove Travel
Bassinet Legs
See images 14 - 18
1. Pull up on one of the yellow rings
located on bottom side of bassinet. Pro
Tip: If you're having trouble folding, try
placing a foot on the bottom of the
bassinet to help hold it in place.
2. Fold bassinet as shown
.
15
3. Disconnect 3 snaps on short side of
basket by unwrapping snaps from bar
on bassinet. Repeat on other side.
4. Flip bassinet upside down, and press
buttons on four legs to remove
bassinet legs.
5. Lift bassinet legs off of bassinet.
To Use Carry Bag
See images -
19 24
• Store product in bag or away from
child when folded.
1. Pull up on one of the yellow rings
located on bottom side of bassinet. Pro
Tip: If you're having trouble folding, try
placing a foot on the bottom of the
bassinet to help hold it in place.
2. Fold bassinet as shown
20 .
3. Flip bassinet upside down, and press
buttons on four legs to remove
bassinet legs.
7
4. Insert folded bassinet and mattress pad
into carry bag.
5. Insert legs into carry bag.
6. Use straps on bag to carry.
How to Clean Mattress Pad
See images 25 - 26
1. Open flap on mattress pad. Remove 2
mattress boards.
2. Remove 2 foam pad. Reverse steps to
re-assemble.
• DO NOT use mattress pad without
boards and foam pad.
• Always assemble mattress pad with
foam pad on top of board, and place
both fully inside mattress pad cover.
• Note: Keep boards free of moisture.
Do not reinsert boards until fabric is
completely dry.
How to Clean
Bassinet Fabric
See images 27 - 28
1. Remove mattress pad.
2. Disconnect 10 snaps and lift bassinet
fabric from frame. Reverse steps to
re-assemble.
