Bertilo Wallstore Kubik Montageanleitung Seite 3

BCK0230(NF)
ID Details in mm (Tolerance/Toleranz ...-+ 2mm)
45 x 773 x 1600
214
42 x 745 x 1320
218
42 x 250 x 1267
215
28 x 28 x 1600
828
14 x 96 x 1600
702
12 x 70 x 840
1096
12 x 42 x 1280
581
12 x 550 x 830
1097
1505
Ø4,5 x 50
1508
Ø4 x 25
1513
Ø3 x 10
1518
1516
Pcs.
x 1
x 1
x 1
x 1
x 1
x 4
x 4
MFP
x 3
x 29
x 30
x 60
x 1
x 4
ID Details in mm (Tolerance/Toleranz ...-+ 2mm)
42 x 745 x 1320
217
12 x 772 x 1315
219
42 x 250 x 1267
216
28 x 28 x 1544
827
14 x 60 x 1600
702-1
12 x 70 x 1295
618
15 x 15 x 1100
708
3 x 1000 x 2000
536
NB! Roofing felt for
initial covering!
1506
Ø3,5 x 35
1510
Ø3 x 19
1556
1517
Pcs.
x 1
x 2
x 1
x 1
x 1
x 9
x 3
x 1
x 107
x 15
x 2
x 2
2
