WE-EF Eco Step Dim Motion Box Handbuch Seite 3

Eco Step Dim® Motion Box
Mastmontage
3 a
A
4 m
Motion Box
1 2 3 4 5
L1
N
1
3 b
ca. 15 - 20 m
1 = L in braun
DALI
2 = N blau
DALI
3 = L out grau
L1
4 = DALI schwarz
N
5 = DALI schwarz
Ø 16 mm
4 m
2
L = 6 m
2
4
ca. 8 - 10 m
