CONNESSIONE ELETTRICA CLASSE I
WIRING FOR VERSIONS CLASS I
6A
ON-OFF / SPD WIRING
7
2,5 Nm
10
CONNECT
MAIN VOLTAGE
CONNESSIONE ELETTRICA CLASSE II
WIRING FOR VERSIONS CLASS II
6
PUSH TO OPEN
L
LINE
GROUND
L
N
N
NEUTRAL
8 mm
H07RN-F
30 mm
3G 1÷2,5 mm
Ø 10÷14 mm
8
CLOSE
1
17 Nm
2 x
CH 13
7
6B
1-10V /DALI WIRING
3
2 x
GLASS
2
2 x
8
ON-OFF WIRING
L
LINE
N
NEUTRAL
L
N
H07RN-F
2x 1÷2,5 mm
Ø 10÷14 mm
L
N
D+
D-
8 mm
H07RN-F
40 mm
5G1÷1,5 mm
2
Ø10÷14 mm
9
SELECT THE
DESIRED
ANGLE
9
8 mm
30 mm
48063620 | ED. 08 | 08 - 2021
L
LINE
GROUND
N
NEUTRAL
1-10V (+)
D+
DALI
1-10V (-)
D-
DALI
