General Description; Scope Of Delivery; Function Description; Summary - Grizzly ASF 3646 L-Lion Originalbetriebsanleitung

GB

General Description

The illustration how to handle the
appliance can be found on page
2-4.

Scope of Delivery

Carefully remove the equipment from the
packaging and check whether the follow-
ing parts are complete:
- Snow thrower with top hand grip and
machine cable
- Central bar
- Ejector chute with deflector flap
- Upper selector rod with handle
- 2 cable holders
- Rechargeable battery
- Battery charger
- Assembly material grip rod
(4 butterfly nuts, 4 screws and
4 washers)
- Shift linkage fastening screw
- Instruction Manual

Function Description

The cordless snow blower is equipped
with an auger with rubber edge for snow
take-up, a robust plastic housing and an
adjustable ejector chute for throwing out
the snow.
The safety key protects the devices from
being started unintentionally.
The machine also has a light to make it
easier to work in poor light in the morning
or evening.
For the function of the operating parts,
please refer to the descriptions below.
58

Summary

1 Upper grip handle
2 Start handle
3 On/off switch lighting (not visible)
4 Lighting
5 Upper selector rod with handle
6 2 butterfly nuts, screws and
washers for securing the top grip
bar
7 Central bar
8 2 cable holders
9 Bottom selector rod
10 Bottom bar
11 Machine housing
12 2 butterfly nuts, screws and
washers for securing the central
bar
13 2 wheels
14 Snow shovel edge
15 Auger (turbine)
16 Ejector chute
17 Carry handle
18 Butterfly nut for adjusting the de-
flector flap (not visible)
19 Deflector flap
20 Device cable
21 Plastic shroud with opening for
selector rod
22 Release button
23 Safety key
24 Hinged cover for rechargeable
battery compartment
25 Button for checking the charge
status of the rechargeable bat-
tery
26 Unlock button - rechargeable
battery
27 Rechargeable battery
28 Power cord for the charger
29 Battery charger
30 4 cross-head screws for mount-
ing the ejector chute
31 Shift linkage fastening screw
32 6-part rubber rim
