Eden Birdlip Bedienungsanleitung

(4’ 10” wide)
Vorschau ausblenden Andere Handbücher für Birdlip:
Inhaltsverzeichnis

Werbung

Verfügbare Sprachen
  • DE

Verfügbare Sprachen

  • DEUTSCH, seite 6

Quicklinks

Diese Anleitung herunterladen
Zero -Threshold Range
Birdlip
(4' 10" WIDE)
Designed &
Manufactured
In the UK
Customer Helpline: +44 (0)1242 676625
All imperial measurements are approximate, for guidance only.
Go to www.edengreenhouses.com for the latest version of the instructions.
Go to "Help & Advice" section for new improved tips and videos.
Note: If you are siting your greenhouses on a concrete/slab base please refer to dimensions given on the front cover. But allow 80mm
extra space on the width for the gutters on each side at eaves level.
If you are siting your greenhouse on earth please refer to the dimensions given in section 0 Foundation.
Mon—Fri 9:00am—5:00pm
1478 mm
mail@eden-greenhouses.com
2
1324mm—1.95m
—4ft
2
1942mm—2.87m
—6ft
2
2560mm—3.78m
—8ft
RN00300817
EM 3.01

Werbung

Inhaltsverzeichnis
loading

Verwandte Anleitungen für Eden Birdlip

Inhaltszusammenfassung für Eden Birdlip

  • Seite 1 Zero -Threshold Range Birdlip 1324mm—1.95m —4ft 1478 mm 1942mm—2.87m —6ft 2560mm—3.78m —8ft (4’ 10” WIDE) All imperial measurements are approximate, for guidance only. Go to www.edengreenhouses.com for the latest version of the instructions. Designed & Go to “Help & Advice” section for new improved tips and videos.
  • Seite 2 Tools and safety equipment Recommended Dear Customer, • Step ladder • Congratulations on purchasing your new Eden greenhouse. Drill (anchoring only) • Spirit level Before you start, please read this instruction booklet carefully. The components for your • greenhouse are in numbered bundles corresponding to the sections in this booklet.

  • Seite 3: Components List

    The gutters will need to be regularly cleared of leaves and debris to ensure (White background) (Black background) efficient drainage. • Replace all broken panes of glass immediately, failure to do so may cause structural failure. • Remove snow loads from the roof. Page 2 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 4 DK - Introduktion Kære kunde Værktøj og sikkerhedsudstyr Tillykke med købet af dit nye Eden-drivhus. Anbefalet Før du begynder, bedes du læse denne vejledning omhyggeligt igennem. • Trappestige Komponenterne til dit drivhus er nummererede bundter, der svarer til sektionerne i •...
  • Seite 5 Set indefra Set udefra effektiv bortledning. (Hvid baggrund) (Sort baggrund) • Udskift straks alle beskadigede glaspaneler, da det ellers kan svække drivhusets struktur. • Fjern sne, der har lagt sig på taget. Page 4 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...

  • Seite 6: Mitgelieferte Werkzeuge

    D - Einleitung Werkzeuge und Sicherheitsausrüstung Empfohlen Sehr geehrter Kunde, • Stehleiter • herzlichen Glückwunsch zum Erwerb Ihres neuen Eden Gewächshauses. Bohrmaschine (nur fürVerankerungsbohrungen) Bevor Sie beginnen, lesen Sie bitte diese Bedienungsanleitung sorgfältig durch. Die • Wasserwaage Komponenten für Ihr Gewächshaus sind in nummerierten Bündeln entsprechend den •...
  • Seite 7 Die Regenrinnen müssen regelmäßig von Laub und Schmutz befreit werden, um (Weißer Hintergrund) (Schwarzer Hintergrund) ungehinderten Abfluss zu gewährleisten. • Kaputte Glasscheiben müssen sofort ersetzt werden, um ein strukturelles Versagen zu vermeiden. • Schneelast vom Dach beseitigen. Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 6...
  • Seite 8 Verktyg och säkerhetsutrustning Rekommenderas Bästa kund, • Trappstege • Borr (endast för förankring) Tack för att du köpt ett Eden växthus. • Vattenpass Läs igenom dessa instruktioner noggrant innan du börjar. Komponenterna till ditt • Måttband växthus har delats in i numrerade buntar som motsvarar de olika avsnitten i dessa •...
  • Seite 9 Följande symboler anger om illustrationerna visar insidan eller utsidan av växthuset: fungerar effektiv. • Byt ut alla trasiga glasrutor genast, annars kan problem uppstå med växthusets Sett inifrån Sett utifrån struktur. (Vit bakgrund) • Snö bör röjas från taket. (Svart bakgrund) Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 8...

  • Seite 10: Outils Fournis

    F - Introduction Cher Client, Outils et équipement de sécurité recommandés • Nous vous félicitons pour l'achat de votre nouvelle serre Eden. Escabeau • Perceuse (pour ancrage Avant de commencer, lisez attentivement cette notice. Les composants de votre serre seulement) sont regroupés en lots numérotés correspondant aux diverses sections de cette notice.

  • Seite 11: Liste Des Composants

    (Fond blanc) (Fond noir) • Remplacez immédiatement toutes les vitres brisées. Si cette précaution n'est pas respectée, cela risque d'entraîner une défaillance structurelle. • Éliminez les amas de neige sur le toit. Page 10 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 12 NL - Inleiding Werktuigen en veiligheidsuitrusting Aanbevolen Geachte klant • Keukentrap Gefeliciteerd met uw aankoop van uw nieuwe broeikas van Eden. • Boor (alleen voor verankeren) Lees deze gebruiksaanwijzing zorgvuldig door voordat u begint. De onderdelen van uw • Waterpas broeikas zijn verpakt in genummerde pakjes, die overeenkomen met de delen van dit •...

  • Seite 13: Lijst Van Onderdelen

    (Witte achtergrond) (Zwarte achtergrond) verwijderen en te zorgen voor efficiënte drainage. • Vervang elke gebroken ruit onmiddellijk, anders kan er structurele schade worden veroorzaakt. • Verwijder lagen sneeuw van het dak. Page 12 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 14 Herramientas y equipos de seguridad recomendados • Escalera de mano Le felicitamos por la compra de su nuevo invernadero de Eden Greenhouses. • Taladro (sólo para anclajes) Antes de empezar, lea atentamente este manual de instrucciones. Las piezas van en •...

  • Seite 15: Listado De Componentes

    Reemplace de inmediato todos los paneles de vidrio que se rompan, ya que si no lo hace puede ocasionar fallos estructurales. • Retire la nieve que se acumule en el tejado. Page 14 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...

  • Seite 16: Attrezzi In Dotazione

    I - Introduzione Attrezzi e attrezzatura di sicurezza consigliati Spettabile Cliente, • Scala Congratulazioni per aver acquistato la nuova serra Eden. • Trapano (solo fissaggio) Prima d’iniziare, leggere attentamente questo libretto d’istruzioni. I componenti della • Livella serra sono raccolti in confezioni numerate corrispondenti alle sezioni di questo •...

  • Seite 17: Elenco Dei Componenti

    Vista dall’esterno un drenaggio efficiente. (Sfondo bianco) (Sfondo nero) • Sostituire tutti i vetri rotti immediatamente, in caso contrario si potrebbe verificare un cedimento strutturale. • Togliere la neve dal tetto. Page 16 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...

  • Seite 18: Sijoituspaikan Valinta

    FI - Esittely Hyvä asiakas Suositellut työvälineet ja suojaimet Olet tehnyt hyvän valinnan hankkiessasi nyt uuden Eden-kasvihuoneen. • Tikkaat • Ennen kuin ryhdyt mihinkään muuhun, lue tämä ohjekirja tarkkaan. Kasvihuoneen osat Pora (vain ankkurointiin) • on koottu numeroituihin nippuihin, joiden numerot viittaavat samalla numerolla ohje- Vesitasain kirjaan merkittyihin asennusvaiheisiin.
  • Seite 19 Räystäät täytyy puhdistaa säännöllisesti lehdistä ja roskista, jotta tehokas veden Sisäpuolelta katsottuna Ulkopuolelta katsottuna (valkoinen tausta) (musta tausta) valuminen voidaan varmistaa. • Vaihda kaikki rikkoutuneet lasilevyt uusiin välittömästi, muussa tapauksessa kasvihuoneen rakenteet voivat vaurioutua. • Luo lumi pois katolta. Page 18 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 20 L) przykręcanych 6 mm x 50 mm kołkami rozporowymi o rozmiarze 7 mm minimum, trzeba wywiercić otwory w płytach lub betonie, wiertłem średnicy 7 mm, jak można zobaczyć w SEKCJI 10 WYKOŃCZENIE. Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 19...
  • Seite 21 (czarne tło) • Wszelkie stłuczone lub pęknięte szyby wymieniać bez zbędnej zwłoki — zaniedbanie tego może spowodować uszkodzenie, lub nawet zawalenie się, konstrukcji. • Z dachu usuwać nagromadzony na nim śnieg. Page 20 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 22 7 mm murbor 1 x 10 mm fastnøkkel og fest med 7 mm plugger og 6 mm x 50 mm skruer minimum som vist i TRINN 10 AVSLUTTENDE. Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 21...
  • Seite 23 Takrennene må renses regelmessig for løv og skitt for å sikre effektivt avløp. (Hvit bakgrunn) (Svart bakgrunn) • Glass som er knust må skiftes ut umiddelbart da dette kan gi strukturell svikt. • Taket skal holdes fritt for store snømengde. Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 22...
  • Seite 24 1264 RP137841264 1757 RP095841757 1882 RP137841882 RP137850414 2500 RP137842500 RP2079110632 RP2079090652-4 1609 RP2079111609 1264 RP2078401264 1492 RP309331492 1882 RP2078401882 1418 RP137841418 2500 RP2078402500 1812 RP228501812 RP228500832 1499 RP2079111499 RP309300636 RN00310237 RP1070400606-25 Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 23...
  • Seite 25 RP102640305 30RH RP2081140305-RH 1733 RP209171733 RP309340315 1034 RP2079111034 RP2081140305 RP235570300 RN00300301 32,000 RN00300412 RN00310450 64,000 RN00300413 N00300210 RP2079110477 N00300205 RN00310413 4,000 RN00300417 95-LH RP2079100315-LH RN00300227BK 95-RH RP2079100315-RH 50/51 N00300605 / 655 Page 24 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 26 N00300602 00682BK N00300603 PT201 N00300604 RN00310443 PT200 12469 12468 PT204 1490 RN00311422 RN00311419 RN00310418 1915 RN00311425 1490 RN00311617 RN00310424 RN00311612 1915 RN00311616 N00300606 RN00311503 RN00311505 RN00310422 RN00311504 RN00310426 20240 Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 25 Page 25...
  • Seite 27 4 x 6 4 x 8 1.95m 2.87m 3.78m 1418mm 1418mm 1418mm 1264mm 1882mm 2500mm 414mm 414mm 414mm 590mm 590mm 590mm 1890mm 2356mm 2874mm NOTE: THIS IS FOR DIMENSION MEASUREMENTS ONLY Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 26 Page 26...
  • Seite 28 (Black background) *NOTE: 4x4 Model extra bolt Required see picture 9 * 4 x 4 4 x 6 4 x 8 1.95m 2.87m 3.78m 1418 1492 1812 1521 1405 Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 27 Page 27...
  • Seite 29 REAR GABLE - BAGGAVL - HINTERGIEBEL - BAKGAVEL - PIGON DERIERE - ACHTERGEVEL - FRONTIS TRASERO - PANNELL OPOSTERIORE- PERAPAATY - TYLNA SCIANA SZCZYTOWA - BAKRE GAVL 4x4 only: Extra bolt 50/ nut 51 to use later Extra bolt 50/ nut 51 to use later Page 28 Page 28 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 30 (Black background) 4 x 4 4 x 6 4 x 8 1.95m 2.87m 3.78m 4000 1757 1492 16 + 45 1499 16 + 45 45 x 2 16 x 2 Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 29 Page 29...
  • Seite 31 FRONT GABLE - FORGAVL - VORDERGIEBEL - FRONTGAVEL - PIGNON DEVANTVOORGEVEL - FRONTIS FRONTAL - PANNELLO FRONTALE - OVIPÄÄTY- PRZEDNIA ŚCIANA SZCZYTOWA - FRONTGAVL Extra bolt 50/ nut 51 to use later Page 30 Page 30 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 32 Extra bolt 50/ nut 51 to use later Viewed from the inside Viewed from the outside 2500 (White background) (Black background) 1264 1882 2500 1609 4x6 - 2.87m 4x4 - 1.95m 4x8 - 3.78m Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 31 Page 31...
  • Seite 33 ASSEMBLE - SAMLING - FENSTER - HOPMONTERING - ASSEMBLAGE - MONTEREN MONTAJE - MONTAGGIO - KOKOAMINEN - MONTAZ STELAZA - MONTERING Viewed from the inside Viewed from the outside (White background) (Black background) Page 32 Page 32 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 34 WINDOWS - VINDUER - FENSTER - FENETRES - RAMEN - VENTANAS - FINESTRE - LUUKUT - WYWIETRZNIKI - VINDUER Viewed from the inside Viewed from the outside (White background) (Black background) 4 x 4 4 x 6 4 x 8 1.95m 2.87m 3.78m 1264 1882 2500 1034 Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 33 Page 33...
  • Seite 35 50 / 51 50 / 51 51 / 50 Preloading of bolt 50 / nut 51 PRE-LOAD 51 / 50 50 / 51 50 / 51 50 / 51 Page 34 Page 34 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 36 WINDOWS - VINDUER - FENSTER - FENETRES - RAMEN - VENTANAS - FINESTRE - LUUKUT - WYWIETRZNIKI - VINDUER Viewed from the inside Viewed from the outside (White background) (Black background) 4 x 4 4 x 6 4 x 8 1.95m 2.87m 3.78m 64000 Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 33 Page 35 Page 35...
  • Seite 37 4 x 4 4 x 6 4 x 8 1.95m 2.87m 3.78m 1.95m 2.87m 3.78m 64000 1733 1733 29 RH 29 LH 30RH 30LH 305 X 610 305 X 212 Page 34 Page 36 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 38 DOOR - DØR - TÜR - PORTE - DEUR - PUERTA - PORTA – OVI – DRZWI - DØR 29 RH 2.5mm Hex Key Viewed from the inside Viewed from the outside (White background) (Black background) 12/13 28/65 28/65 122 + 107 29 RH 29 RH Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 35 Page 37...
  • Seite 39 DOOR - DØR - TÜR - PORTE - DEUR - PUERTA - PORTA – OVI – DRZWI - DØR 30RH 29 RH 29 RH 30RH 30RH 30RH 30RH Page 36 Page 38 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 40 DOOR - DØR - TÜR - PORTE - DEUR - PUERTA - PORTA – OVI – DRZWI - DØR 2.5mm Hex Key Viewed from the inside Viewed from the outside (White background) (Black background) 29 LH 29 LH Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 37 Page 39...
  • Seite 41 DOOR - DØR - TÜR - PORTE - DEUR - PUERTA - PORTA – OVI – DRZWI - DØR 30LH (x2) 30LH 30LH SQUEEZE LEVER & SLIDE OUT TO REMOVE AS LEFT 114 A 114 B Page 38 Page 40 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 42 97 RH 114B 114B 61mm Hole patterns on sliders may vary. If so, follow dimensions given above +/- 2mm Hålmönster kan variera, om så, följ måtten enligt ovan +/- 2mm Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 39 Page 41...
  • Seite 43 97 LH 114B 114B 61mm Hole patterns on sliders may vary. If so, follow dimensions given above +/- 2mm Hålmönster kan variera, om så, följ måtten enligt ovan +/- 2mm Page 40 Page 42 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 44 97RH Viewed from the inside Viewed from the outside (White background) (Black background) 2.5mm Hex Key SQUEEZE LEVER & SLIDE OUT TO REMOVE AS LEFT 114 A 114 B Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 39 Page 43...
  • Seite 45 51 x 3 118 x 3 2.5mm Hex Key 103/ 118 x 3 97RH 114 B 102 x Visit www.edengreenhouses.com “Help & Advice” for Hints & Tips and videos Page 40 Page 44 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 46 97LH Viewed from the inside Viewed from the outside (White background) (Black background) 2.5mm Hex Key SQUEEZE LEVER & SLIDE OUT TO REMOVE AS LEFT 114 A 114 B Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 39 Page 45...
  • Seite 47 51 x 3 118 x 3 2.5mm Hex Key 103/ 97LH 118 x 3 114 B 102 x 3 Visit www.edengreenhouses.com “Help & Advice” for Hints & Tips and videos Page 40 Page 46 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 48 LOCATING - PLACERING – FIXIERUNG – PLACERING – EMPLACEMENT – LOCATIE – UBICACIÓN – UBICAZIONE – SIJOITUS - PRZYWIERDZENIE - PLASSERING Viewed from the inside Viewed from the outside (White background) (Black background) 50/51 77mm Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 41 Page 47...
  • Seite 49 UBICACIÓN – UBICAZIONE – SIJOITUS - PRZYWIERDZENIE - PLASSERING 14/13 13/14 *TIP: Before fitting doors, please make sure the base and door aperture are level and square to ensure doors run smoothly* Image for illustration purposes only Page 42 Page 48 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 50 * TIP: Remove lintel (20) to ease fitting of sliders, then replace * Viewed from the inside Viewed from the outside (White background) (Black background) 114B 114B 18/97 18/97 *NOTE: Open doors to fully engage * Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 43 Page 49...
  • Seite 51 LOCATING - PLACERING – FIXIERUNG – PLACERING – EMPLACEMENT – LOCATIE – ŻALUZJE LOUVRE – LUFTINTAG - UBICACIÓN – UBICAZIONE – SIJOITUS - PRZYWIERDZENIE - PLASSERING 64000 HORTI 610mm 504/402 895mm = 42 Page 44 Page 50 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 52 457 x 334 x 25 GLH 1037 457 x 348 x 513 x 348 GLH 1038 610 x 265 GLH 1039 LOUVRE 610 x 402 GLH 1040 ONLY N00300205 N00300210 RN00310458 Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 47 Page 51...
  • Seite 53 12469 fitting of the capping* R (58) RN00310458 40 REQUIRED ONLY *NOTE: See online video “Help & Advice” * W CLIPS N00300205 FOR THE DOOR 360/437 1915 Page 48 Page 52 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 54 RN00311612 L1, L3, soapy water to ease 1920 RN00311616 fitting of the capping* RN00311503 20240 RN00311505 RN00311504 H & G N00300205 40 REQUIRED CLIPS FOR DOOR ONLY Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 47 Page 53...
  • Seite 55 FINISHING – AFSLUTNING – FERTIGSTELLUNG – SLUTFÖR - POUR FINIR- AFWERKING – ACABADO – FINITURA – VIIMEISTELY – WYKMOCZENIE - AVSLUTTENDE 1,2,3,4,5 1,2,3,4,5 * TIP: For aluminium finish models due to binding, a little lubricant may be needed to ease fitting of vent / windows * Page 54 Page 50 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 56 FINISHING – AFSLUTNING – FERTIGSTELLUNG – SLUTFÖR - POUR FINIR- AFWERKING – ACABADO – FINITURA – VIIMEISTELY – WYKMOCZENIE - AVSLUTTENDE 1,2,3 1,2,3 1400 105B 105A 105B *NOTE: 105 consists of two parts. Simply unscrew the inside to allow fitting. * Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 49 Page 55...
  • Seite 57 FINISHING – AFSLUTNING – FERTIGSTELLUNG – SLUTFÖR - POUR FINIR- AFWERKING – ACABADO – FINITURA – VIIMEISTELY – WYKMOCZENIE - AVSLUTTENDE 105B 105B 105A 116 /117 Page 52 Page 56 Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
  • Seite 58 As shown in picture 2 * *NOTE: For securing with screws, please see below for minimum requirements. * Ø 7mm Ø 7mm Ø 6mm x 50mm Eden Greenhouses Customer Helpline: +44 (0)1242 676625 Page 51 Page 57...

  • Seite 60: Year Warranty

    This warranty does not extend beyond the cost of any faulty component referred to above. This warranty applies in the United Kingdom only. Eden Greenhouses (Part of Juliana Group Ltd.) The Distribution Centre Stoke Orchard Cheltenham, Gloucestershire GL52 7RS Eden Greenhouses Customer Helpline: +44 (0)1242 676625...
