Eldom PH20 Bedienungsanleitung Seite 4

GENERAL DESCRIPTION
1. Thermostats
2. Heating plates
3. Control lights
4. Housing
TECHNICAL DATA
- power: 2300W (2 x 1150W)
- supply voltage: 230V ~ 50Hz
OPERATION
The ceramic cooker allows to prepare food in many different ways (cooking, frying, etc.)
The use of infrared lamp in appliance allows to reach rapidly required temperature,
which saves time and reduces power consumption.
Before operating and plugging in the appliance, set thermostats (1)
in the position "MIN" (the appliance switched off).
Position the appliance on a level, dry, stable and high-temperature resistant surface. The housing
(4) heats up considerably when operated. Thus, the space of at least 5 cm from the sides of the
device should be provided.
To ensure free and safe access to the appliance, place it at a proper height.
- plug in the appliance
- place a dish with products on the heating plate (2)
- switch on the appliance selecting the working temperature of the thermostat (1).
Each heating plate (2) is controlled by a separate thermostat (1).
Both plates can be used at the same time.
Thermostat enables smooth adjustment of the temperature.
Settings 1-3 correspond to the lower temperature proper for heating meals.
Settings 4 - MAX - high temperature intended for cooking. Operation of the appliance is signalled
by the control light (3).
The operation of the appliance is signalled by control lights
Po zakończeniu pracy termostaty (1) ustawić w pozycji „MIN" i odłączyć urządzenie od sieci.
During the first activation of the appliance, a specific smell can be emitted from the heating
elements and the insulation. It is a normal occurrence.
In order to ensure safety and high efficiency of the operation, use only dishes with flat bottoms
and of a proper diameter which guarantee stability and good contact of the dish with the heating
plate
CLEANING AND MAINTENANCE
Before cleaning, unplug the appliance and wait until it cools down completely.
- Do not immerse the appliance in water or wash it in a dish-washer machine.
- All surfaces can be cleaned only by wiping them with a soft, damp cloth with the addition
of gentle cleaning agents.
- Do not use abrasive agents.
USER MANUAL
ELECTRIC COOKER PH20
2
1
3
3
(3).
4
2
4
1
FOT. 2
