Ground Zero URANIUM Serie Bedienungsanleitung Seite 4

Modell
Kategorie
Impedanz (nominal)
Frequenzgang
Korbmaterial
Membran
Antrieb
Schwingspule
Belastbarkeit (RMS)
Belastbarkeit (max.)
Resonanzfrequenz
Wirkungsgrad (SPL)
R
e
Q
ms
Q
es
Q
ts
V
as
M
ms
B
L
R
ms
C
ms
L
E
Xmax (Auslenkung)
Außendurchmesser (A)
Abmessungen Einbaudurchmesser (B)
Einbautiefe (C)
GROUND ZERO is using the worldwide accepted KLIPPEL
development during the German in-house development as well as for QC reporting for most production lines at the
factory. The results of LPM and LSI measurements are the basis for evaluating and verifying further development
enabling to offer perfectly working products in any practical application. Continuous and advanced trainings for
development employees ensure the highest possible qualification.
KLIPPEL ® is a registered trademark of
GROUND ZERO GZUK 165SQ
Technische Daten
165 mm SQ Tiefmittelton-Lautsprecher
Aluminum-Druckguss
Eloxiertes Aluminium
120 Watt (60 Hz HPF @ 12dB/Okt.)
180 Watt (60 Hz HPF @ 12dB/Okt.)
Technische Parameter (TSP)
Abmessungen
Verified with KLIPPEL
KLIPPEL GmbH
GZUK 165SQ
4 Ohm
40 Hz – 3.5 kHz
Neodym-Magnet
50 mm Kupfer
54.6 Hz
87 dB
3.2 ohms
3.87
0.77
0.64
12.6 L
16.3 g
4.84 N/A
1.44 kg/s
0.52 mm/N
0.17 mH
12 mm gesamt
165 mm
144 mm
63 mm
®
®
R&D Analyzer KA3 measurement system for speaker
URANIUM SERIES
