- Seite 1 MSI MP54G5 (MS-6833B) Wireless 11g MiniPCI Card Quick User’s Guide Downloaded from www.Manualslib.com manuals search engine...
- Seite 2 Übereinstimmung mit den grundlegenden Anforderungen und den anderen relevanten Vorschriften der Richtlinie 1999/5/EG befindet. Die Konformitätserklärung kann auf folgender website eingesehen werden: http://www.msi-computer.de/support/dl_man.php Hereby, Micro Star International CO., LTD declares that this device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
- Seite 3 - open computer systems, etc. - Microwave oven, etc, Communication (exchange data) is dependent on the software of the WLAN or Bluetooth ® devices. MSI Technology GmbH Hanauer Landstraίe 306 60314 Frankfurt Telefon: +49 (0)69 40893-0 Telefax: +49 (0)69 40893-202 Downloaded from www.Manualslib.com...
-
Seite 4: Fcc Caution
FCC Caution 1. The device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. -
Seite 5: Important Safety Precautions
Important Safety Precautions Always read and follow these basic safety precautions carefully when handling any piece of electronic component. Keep this Quick User’s Guide for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equipment from overheating. -
Seite 6: Inhaltsverzeichnis
Important Safety Precautions ................... v Chapter 1. Introduction ....................1 1.1 MSI MP54G5 Wireless 11g MiniPCI Card ............. 1 1.2 How MSI MP54G5 Wireless 11g MiniPCI Card Works ........ 2 1.2.1 In WLAN Environment ................2 1.3 Specifications ...................... 4 1.4 System Requirements .................. -
Seite 7: Msi Mp54G5 Wireless 11G Minipci Card
Introduction >>> 1.1 MSI MP54G5 Wireless 11g MiniPCI Card The MSI MP54G5 Wireless 11g MiniPCI Card, is a Type IIIB card, which can be used to integrate with such systems as notebook, mini-barebone and portable PC. With MSI MP54G5 Wireless 11g MiniPCI Card embedded inside, a system could provide users with the ability and flexibility to connect up to Internet wirelessly via 802.11g with speed up to 54Mbps. -
Seite 8: How Msi Mp54G5 Wireless 11G Minipci Card Works
>>> 1.2 How MSI MP54G5 Wireless 11g MiniPCI Card Works 1.2.1 In WLAN Environment Ad-hoc Mode : An Ad-hoc network is a local area network or other small network, especially one with wireless or temporary plug-in connections, in which some of the network devices are part of the network only for the duration of a communications session. - Seite 9 Internet, email, file transfer, and printer sharing. The scale and range of the Infrastructure networking are larger and wider than that of the Ad-hoc networking. MSI MP54G5 Wireless 11g MiniPCI Card MSI MP54G5 Wireless 11g MiniPCI Card Downloaded from www.Manualslib.com...
-
Seite 10: Specifications
>>> 1.3 Specifications Network Standard IEEE 802.11b/g Frequency Band 2.400-2.4835GHz Form Factor Compliant with the 32-bit MiniPCI Type IIIB Antenna Connector Two antenna connectors Data Rate IEEE802.11g (auto-fallback): - OF DM: 54, 48, 36, 24, 18, 12, 9 and 6 Mbps IEEE 802.11b (auto-Fallback): - CCK: 11, 5.5 Mbps - DQPSK: 2 Mbps... - Seite 11 Temperature Operating C to 65 Storage C to 100 Humidty 10% - 90% (non-condensing) Power Consumption 802.11g (54Mbps) 310mA@3.3v in continue Tx 260mA@3.3v in continue Rx 160mA@3.3V in Standby mode 802.11b(11Mbps) 350mA@3.3V in continue Tx 240mA@3.3V in continue Rx 160mA@3.3V in Standby mode Operating Voltage 3.3V +/- 5% Output Power...
-
Seite 12: System Requirements
>>> 1.4 System Requirements Before installing MSI MP54G5 Wireless 11g MiniPCI Card, your PC should meet the following items: - One desktop/notebook PC with an available MiniPCI slot. - Windows 98SE/ME/2000/XP/XP 64-bit operating system. ® - Minimum 5MB free disk space for installing the driver and utilities. -
Seite 13: Product View
>>> 1.6 Product View WLAN 11g antenna connectors Connect to external antennas for enhanced data transmission and reception. The external antennas are well designed on the desktop or note- book computers. Golden Finger Downloaded from www.Manualslib.com manuals search engine... -
Seite 14: Hardware Installation
Hardware Installation The following diagrams provide you a basic installation for your MSI MP54G5 Wireless 11g MiniPCI Card. The instruction below is suitable for most computers with MiniPCI slot. For more information about the MiniPCI module, please refer to your computer’s manual. -
Seite 15: Software Installation
Setup CD to copy files during the installation. Please NOTE that the MSI MP54G5 Wireless 11g MiniPCI Card should be installed into your computer before installing the driver and utility. Then, the operating system will detect a new device and start to configure the new device. -
Seite 16: Software Setup
>>> 3.1 Software Setup After installing the MSI MP54G5 Wireless 11g MiniPCI Card to your computer and then turning on the computer, the operat- ing system will detect a new device and start the configuraton automatically. Please CANCEL the pop-up window from Found New Hardare Wizard to install necessary driver and utility from the InstallShield Wizard of your Software CD. - Seite 17 The program will copy the necessary files to the system. The ST EP progress indicator shall show the installing status. Click Finish when the installation is completed. The MSI Wire- ST EP less LAN icon will appear in the status area.
-
Seite 18: Infrastructure Mode
Networking Setup Since the MSI MP54G5 Wireless 11g MiniPCI Card is in- stalled in your computer, you have to configure the settings for communication to start working in your network environment. >>> 4.1 Infrastructure Mode Infrastructure mode allows your computer to communicate with the other computers in the network through an Access Point. - Seite 19 In the tab of Site Survey, select the network you want, and ST EP then click Connect. You also can click Rescan to search the available Access Point in the network again. Select If the Access Point selected to connect has been connected and ST EP had set up the Authentication and Security, you need to have the WPA Pre-shared Key or WEP Key beforehand from the...
- Seite 20 Please refer to page 15 for more detail configuration regarding ST EP Add to Profile selection. Advanced network settings: Click the Advanced in the MSI Wireless Utility window to set ST EP advanced network settings. Wireless mode: Select wireless mode. 802.11 B/G mix, 802.
- Seite 21 Radio Off: Indicate to turn off radio. Apply: Apply the above changes. Add Profile to keep your favorite wireless settings: Click the Profile in the MSI Wireless Utility window to select ST EP Add or click Add to Profile after you select one of available Access Point under Site Survey window to configure your favorite wireless settings.
- Seite 22 After click Add to bring up the Configuration dialogue ST EP window as below. Profile Name: User chose name for this profile. SSID: User can key in the intended SSID name or use pull . Power Save Mode: Choose from CAM (Constantly Awake Mode) or Power Saving Mode.
- Seite 23 Preamble: There are three types, Auto, Long and Short are supported. Ad hoc wireless mode: There are five types. 802.11B only, 802.11 B/G mix, and 802.11G only modes are supported. I. RTS Threshold: User can adjust the RTS threshold number by sliding the bar or key in the value directly II.
-
Seite 24: Ad-Hoc Mode
- All the computers connected should be set to Ad-hoc mode. - The computers have the same SSID (network name) setting. To build the Ad-hoc network: Click the MSI Wireless LAN icon to bring up the ST EP Wireless Network Connection window. Then, click Profile tab. Click Add. - Seite 25 Check Network Type option and select Ad-hoc mode to enable ST EP the Ad-hoc mode. Set the SSID Select Click Authentication and Security to setup Authentication ST EP Type, Encrypation and WPA Preshared Key. Set the configuration for your needs. Downloaded from www.Manualslib.com manuals search engine...
- Seite 26 CE Compliance Booklet Downloaded from www.Manualslib.com manuals search engine...
- Seite 27 Table of Content English................1 Detusch ................. 2 Français................. 3 Čeština................4 Dansk................5 Nederlands ..............6 Eesti ................7 SUOMEKSI ..............8 Ελληνικάη..............9 Magyar ................10 Italiano ................11 Latviska ................. 12 Lietuvių................13 Malti ................14 Polski ................15 Português..............
-
Seite 28: English
- Heaters, ferroconcrete, etc. - open computer systems, etc. - Microwave oven, etc, Communication (exchange data) is dependent on the software of the WLAN or Bluetooth® devices. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... - Seite 29 - Mikrowellenherde, etc, Die Kommunikation zwischen unterschiedlichen WLAN- oder Bluetooth® -Geräten ist von der jeweiligen Software und dem entsprechenden Versionsstand abhängig MSI Technology GmbH. Frankfurt a. M. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine...
-
Seite 30: Français
- Chauffage, bétons armés, etc. - boîtier d’ordinateur non fermé. - Micro-ondes, etc. La communication (échange des données) dépend du logiciel des dispositifs WLAN ou Bluetooth®. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 31: Čeština
- budovy, stromy atd. - topidla, železobeton atd. - otevřené počítačové systémy atd. - mikrovlnná trouba atd. Komunikace (výměna dat) závisí na softwaru zařízení WLAN nebo Bluetooth®. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 32: Dansk
- Bygninger, træer, osv. - Varmekilder, jernbeton, osv. - Åbne computersystemer, osv. - Mikroovne, osv, Kommunikation (dataudveksling) er afhængig af softwaren til WLAN eller Bluetooth® enhederne. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 33: Nederlands
- Verwarmingen, gewapend beton, etc. - Open computer systemen, etc. - Magnetron-oven, etc, Communicatie (uitwisselen van data) hangt af van de software van het WLAN of Bluetooth® apparaat. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 34: Eesti
- igat liiki kõrgsageduskiirgus, - ehitised, puud jne, - kütteseadmed, raudbetoon jne, - avatud arvutisüsteemid jne, - mikrolaineahjud jne. Side (andmevahetus) oleneb WLAN- või Bluetooth®-seadmete tarkvarast. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 35: Suomeksi
- mikä tahansa korkeataajuinen säteily, - rakennukset, puut, jne. - lämmitin, teräsbetoni, jne. - avoimet tietokonejärjestelmät, jne. - mikroaaltouuni, jne. Tietojen vaihto riippuu WLAN- tai Bluetooth®-laitteiden ohjelmistoista. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 36: Ελληνικάη
- Καλοριφέρ, μπετόν-αρμέ, κτλ. - αναμμένα συστήματα υπολογιστών, κτλ. - Φούρνος μικροκυμάτων, κτλ, Η επικοινωνία (ανταλλαγή δεδομένων) εξαρτάται από το λογισμικό των συσκευών WLAN ή Bluetooth®. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 37: Magyar
- fűtőtestek, vasbeton, stb. - nyitott számítógéprendszerek, stb. - mikrohullámú sütő, stb. A kommunikáció (adatforgalom) függ a szoftvertől amelyek a WLAN vagy Bluetooth® eszközöket működtetik. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 38: Italiano
- Caloriferi, cemento armato, ecc. - Computer aperti, ecc. - Forni a microonde, ecc, La comunicazione (scambio di dati) dipende dal software delle periferiche WLAN o Bluetooth®. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 39: Latviska
- ēkas, koki u.c. - sildķermeņi, dzelzsbetons u.c. - atvērtas datorsistēmas u.c. - mikroviļņu krāsns u.c. Komunikācija (datu apmaiņa) ir atkarīga no WLAN vai Bluetooth® ierīču programmatūras. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 40: Lietuvių
Lietuvių Šiuo dokumentu Micro Star International CO., LTD, MSI pareiškia, kad šis prietaisas atitinka pagrindinius 1999/5/EB direktyvos reikalavimus ir kitas atitinkamas sąlygas. Atitinkamą Atitikimo pažymėjimą galima rasti internete adresu: IEEE 802.11b/g ir Bluetooth® 2.4 GHz veikimas Europa: dažniai: 2.400 – 2.4835 GHz Prancūzija: dažniai: 2.4465–... -
Seite 41: Malti
- Ħiters, konkrit bil-ħadid, eċċ. - sistemi tal-kompjuter miftuħin, eċċ. - Fran tal-majkrowejv, eċċ. Il-kommunikazzjoni (skambju ta’ data) hija dipendenti fuq is-software għall-apparat tal-WLAN jew Bluetooth®. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 42: Polski
- budynki, drzewa itd. - grzejniki, beton, żelazo, - otwarte obudowy komputerów, - kuchenki mikrofalowe itp. Połączenie (wymiana danych) zależy od oprogramowania urządzeń WLAN lub Bluetooth®. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 43: Português
- Edifícios, árvores, etc. - Aquecedores, etc. - Sistemas de computador abertos, - Forno Microondas, A comunicação (intercâmbio de dados) depende do software dos dispositivos WLAN ou Bluetooth®. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 44: Slovensky
- Budovy, stromy, atď. - Ohrievače, železobetón, atď. - otvorené počítačové systémy, atď. - Mikrovlnná rúra, atď, Komunikácia (výmena dát) je závislá od softvéru WLAN alebo Bluetooth® zariadení. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 45: Slovenèina
- grelci, železobeton, ipd. - odprti računalniški sistemi, ipd. - mikrovalovne peči, ipd. Komunikacija (prenos podatkov) je odvisna od programske opreme WLAN ali Bluetooth® naprave. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 46: Español
Edificios, árboles, etc. Calentadores, hormigón armado, etc. Sistemas informáticos abiertos, etc. Microondas, etc La comunicación (intercambio de datos) depende del software de los dispositivos WLAN o Bluetooth® © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine... -
Seite 47: Svenska
– Byggnader, träd o.s.v. – Värmare, betongjärn o.s.v. – öppna datorsystem o.s.v. – Mikrovågsugn o.s.v. Kommunikation (utbyte av data) är beroende av WLAN eller Bluetooth®- anordningarnas mjukvara. © Copyright MSI Technology GmbH 2005. All rights reserved. Downloaded from www.Manualslib.com manuals search engine...
