Adjust the picture size and focus
Refer to "Image Projection" in the projector operation manual for information on adjusting the
focus and picture size.

Handling Precautions

● Do not disassemble this lens.
● Touching any other internal part could cause personal injury or machine malfunction.
● Do not touch any glass or protruding part of the lens. This may cause personal injury
● When maintaining the projector the following points should be noted.

Supplied Accessories

Specifications
AN_PH30EZ_Lens_E.p65
Downloaded from: http://www.usersmanualguide.com/
Please refer to your authorized dealer for any maintenance and inspections requiring an open
cabinet.
and reduced performance of the projector.
• When cleaning the lens be sure to use a commercial air blower or lens cleaning paper (used
in cleaning glasses and cameras).
• The surface of the lens is very delicate. Do not allow hard objects to bump or rub against it.
• Lens cover – 1
• Lens securing screws – 3
• Lens cap (rear) – 1
• Operation manual (this manual)
Product type
Model
Type of lens
Picture size (diagonal)
Focal length
F no.
Throw ratio
Weight
Dimensions of lens
Depth of projector with the
lens attached
2
• Lens ring (silver flange) – 1
• Lens cap (front) – 1
• Installation manual
Standard zoom lens for projector
AN-PH30EZ
Zoom lens
40'' to 300'' (4:3)
25.6 mm (1 1 / '') – 31.3 mm (1
64
1.8 – 2.0
1:1.8 – 2.2
Approx. 1,100 g (2.43 lbs.)
ø80.4 × 166.2 mm (6 35 / '') (main body only)
64
471 mm (18 35 / '')
64
