STEP 4
Install bracket
Place the bracket over the
ange so the holes in the
ange align to the holes in
the bracket. Use the two
mounting screws to attach
the bracket to the ange.
NOTE: Continue to tighten these screws until
the bracket makes contact with the ange. The
rubber feet will compress as you tighten the screws.
STEP 5
Attach the display to the VESA mount
Have a friend hold the
monitor steady while you
use the four VESA screws
and washers to attach the
display to the VESA mount.
