Air diagram
Nosepiece
No.
Mark
6.4
1
Q
General flat
nosepiece
4.8/5.0
2
P
General flat
nosepiece
6.4
l
3
Flat
on the tool
nosepiece
6.4
L
4
Concave
nosepiece
4.8
5
J
Concave
nosepiece
6.4
6
M
Convex
nosepiece
4.8
Convex
7
K
nosepiece
DL 7.8
8
DL
nosepiece
DL 6.2
nosepiece
9
DL
DL 5.2
DL
nosepiece
10
Nosepiece Feature
Type
Schematic
Size
Type
Schematic
Size
Type
Schematic
Size
Type
Size
Type
Size
Type
Schematic
Size
Type
Schematic
Size
Type
Schematic
Size
Type
Schematic
Size
Type
Schematic
Size
Application and Riveted shape
All material:
Standard open/close end, Avdel® Interlok®, Huck® Magnalok®, Huck® MGL100 or similar function rivet.
Countersunk head(Interlok® / Magnalok®): φ6.4mm;
Dome/Countersunk head(Standard open/close end, Single grip): φ6.0mm/6.4mm.
All material:
Standard open/close end, Single grip, Avdel® Interlok®, Huck® Manalok® or similar function rivet.
Countersunk head(Avdel® Interlok® / Huck® Magnalok®): φ4.8mm;
Dome/Countersunk head(Standard open/close end, Single grip): φ4.8mm/5.0mm.
All material: Avdel® Hemlok® 2221, 2241; Huck® ABP-R8,ABP-B8; or similar function rivet.
Dome head: 6.4mm.
All material: Avdel® :Interlock® SSPI，BAPI; Huck®: MGLP-R/B/U; or similar function rivet.
Dome head: 6.4mm.
All material: Avdel® :Interlock® SSPI，BAPI; Huck®: MGLP-R/B/U; or similar function rivet.
Dome head: 4.8mm.
All material: Avdel® Monobolt® 2771, 2774, 2711, 2761, 2764; or similar function rivet.
Dome head: φ6.4mm
All material: Avdel® Monobolt® 2771, 2774, 2711, 2761, 2764; or similar function rivet.
Dome head: φ4.8mm
All material: Gesipa®: BULB-TITE® or similar function rivet.
Dome head: φ7.8mm
All material: Gesipa®: BULB-TITE® or similar function rivet.
Dome head: φ6.2mm
All material: Gesipa®: BULB-TITE® or similar function rivet.
Dome head: φ5.2mm
