Messingschlager 100 Gebrauchsanweisung

MANUAL FREESTYLE SCOOTER ›100‹
These operating instructions must be read and understood before using this
product for the first time. Keep these operating instructions and pass them on
to subsequent users
Aluminium T-bar Alum
Allen Key ey
Aluminium Triple Clamp Alum
Fork Fork Stem
MOUNTING
1. Place the triple clamp over the vertical tube of the T-bar, than insert the
T-bar onto the fork stem.
2. Tighten all three screws with the enclosed Allen key.
SAFETY INSTRUCTIONS
1. Adult assembly required.
2. This product is for age 5+.
3. Rider weight: >20 kg up to max. 100 kg
4. Always wear a helmet, knee & elbow pads when riding your scooter keep
the helmet chinstrap securely buckled.
5. Only use after readiness for use to prevent injuries caused by slipping and
entrapment
6. Always wear closed shoes when riding your scooter.
7. Ride on smooth, paved surfaces away from motor vehicles.
8. Avoid sharp bumps, drainage grates, and sudden surface changes. scooter
may suddenly stop.
9. Avoid streets and surfaces with water, sand, gravel, dirt, leaves, and other
debris. Wet weather impairs traction, braking, and visibility.
10. Do not ride at night.
11. Brake will get hot from continuous use. Do not touch after braking.
12. Avoid excessive speed associated with downhill rides.
13. Adult must assist children in the initial adjustment.
14. Obey all local traffic and scooter riding laws and regulations.
15. Watch out for pedestrians.
16. Check and secure all fasteners before every ride.
17. The scooter is designed for one rider at a time. Do not allow 2 children to
ride at the same time.
18. Do not use the scooter if it has any damage. Replace worn or broken parts
immediately.
19. This scooter is only for teenagers and adults, it is not a toy - it's a sport item
for physical exercise, and is not designed to be used in extreme sports such
AGE as jumps, ramps, ollies.
5+ 20. For safety and respect of others, stay at a safe distance from pedestrians and
others street users. To be used preferably on flat and clean, gravel and
grease-free areas. Avoid bumps and drains as they are potential accident
>20 KG- hazards.
MAX.
21. Warning: when using the scooter, protective gear must be worn at all times,
100 KG
including at least: wrist guard, helmet, knee pads, and elbow pads.
22. Check the steering mechanism before and after each use, i.e. height of
handlebar, tightness of nuts, right-angle of handlebar and front wheel.
Check that all connection elements such as the brake, handlebar tube quick
PROTECTION
lock system, wheels axles and level of wheel wear are well-adjusted.
23. Use : stand on the scooter with a hand on each handle and push along with
one foot to go forward; proceed with caution at the start.
Braking: the brake is located at the back of the scooter; when necessary,
apply the brake to slow down. The brake should be applied gently to avoid
skidding or loss of balance.
24. We strongly advise that shoes be worn when using your scooter, but also
pants, long sleeves shirts, and of course complete protective gear to avoid
injury in case of a fall.
25. The scooter does not have any lights; it, therefore, should not be used at
night or at time when visibility is low.
26. The metal or aluminium brake can heat up after several uses; avoid
touching it during and after use.
27. The scooter is not designed to be dropped when not in use. If the scooter is
dropped after use over a period of time, the plastic end piece, the foam and
the aluminium tubing will be damaged.
28. Do not play on or near public highways, roads or traffic. Using this scooter
on the public highway can be dangerous
29. This product is not a road vehicle and should be used for leisure purposes
only.
CARE AND STORAGE
1. Keep the product in a dry place. If the scooter gets wet, dry metal parts to
prevent rusting.
2. Clean with damp cloth. Do not use solvents or bleaches for clean.
3. Wheel bearings: avoid going through water, oil or sand as this can damage
wheel bearings. To look after the wheel bearings, systematically check that
the wheels turn properly by turning the scooter upside-down and using
your hand to spin the wheels. If the wheels do not spin they must then be
removed to check their condition. First unscrew the wheel axle, remove the
axle and detach the wheel, then carefully push the two wheel bearings out
of their housing. If they are chipped or dented, new ones should be bought.
If there is no visible damage, they must then be oiled. To do this, remove all
traces of grease, mud or dust with a kitchen towel or cloth, and re-oil them
with a grease spray or by leaving them to soak overnight in cooking oil (turn
them several times in the oil first). Before connecting, remove the grease
from all contact surfaces between the bearing and the wheel or axle to
prevent the bearing from slipping and premature wear. After that, insert the
wheels and mount them back into the scooter. If anything is unclear, please
contact your specialist dealer.
4. Wheels: the wheels wear down with time and can be pierced if overly used
on rough surfaces. the back wheel on which the brake is applied is particu-
larly affected and tends to lose its curved shape after several hours of
braking. In the interests of safety, they should be checked regularly and
changed if necessary.
5. Modifications: the original product must by no means be modified except
for the maintenance related changes mentioned in these instructions.
6. Nuts and axles: these should also be checked regularly. They can become
loose after a while in which case they should be tightened. They can
become worn and not tighten properly, in which case they should be
replaced.
With these final instructions for your safety in mind, get started with the scooter
and enjoy yourself.
WARNING
Not suitable for children under 3 years. Choking hazard.
Protective equipment should be worn. Maximum rider weight 100 kg.
Tested according to EN 14619
Art. 659935
