All manuals and user guides at all-guides.com KOMMODE KOMMODE COMMODE Montageanleitung Instructions de montage CASSETTIERA CHEST OF DRAWERS Istruzioni per il montaggio Assembly instruction IAN 111183 1 / 14...
Seite 2
All manuals and user guides at all-guides.com 2 / 14 35.15 2455460 15/06/15...
Seite 3
All manuals and user guides at all-guides.com Sie benötigen: Vous avez besoin de: Le servono: You need: Beschläge / Ferrures pour meubles / Guarnizioni / Fittings 5,0x35 3 x ZB 7 1 x VB10 10 x VB1 10 x VB15 10 x VB4 M4x8 6,3x19...
Seite 4
All manuals and user guides at all-guides.com Sicherheitshinweis: Achtung: Bei mangelhafter Montage besteht Gefahr für die Sicherheit. Aufbau durch fachkundiges Personal empfohlen! Pflegehinweis: Bitte nur mit einem Staubtuch oder einem feuchten Lappen reinigen. Keine scheuernden Putzmittel verwenden! Bestimmungsgemäße Verwendung: Produkt nutzbar für den privaten Wohnbereich. Note de sécurité: Attention: En cas de montage incorrect, il y a risque pour la sécurité.
Seite 5
All manuals and user guides at all-guides.com M4x22 3 x ZB7 8 x SG11 4 x GR23 ZB 7 ZB 7 GR 23 SG 11 SG 11 90° ZB 7 GR 23 SG 11 SG 11 ZB 7 5 / 14...
Seite 6
All manuals and user guides at all-guides.com 3,5x20 ZB 4 8 x SP3 SP 3 SP 3 ZB 4 ZB 4 SP 3 90° ZB 4 SP 3 SP 3 ZB 4 ZB 4 6 / 14...
Seite 7
All manuals and user guides at all-guides.com 5,0x35 6 x VB1 6 x VB4 4 x VB15 VB 15 VB 15 VB 15 VB 15 VB 1 VB 1 VB 4 VB 4 VB 1 VB 1 VB 1 VB 4 VB 4 VB 4 VB 1...
Seite 8
All manuals and user guides at all-guides.com 6,3x19 15x6 5,0x35 4 x VB1 16 x SO5 16 x ZB12 6 x VB15 4 x VB4 4 x GL7 8 x SK8 SO 5 SO 5 VB 1 SK 8 SO 5 SO 5 SK 8 SO 5...
Seite 9
All manuals and user guides at all-guides.com VB 1 VB 1 9 / 14...
Seite 10
All manuals and user guides at all-guides.com 3,5x20 ZB 4 10 x SO3 4 x SP3 SP 3 ZB 4 SP 3 ZB 4 SP 3 ZB 4 SP 3 SO 3 ZB 4 SP 3 ZB 4 90° 10 / 14...
Seite 11
All manuals and user guides at all-guides.com 1 x VB10 +/-1 1 x VB9 VB10 4 x AK3 VB 9 VB 10 AK 3 Wandmontage: Bei Verbindungsmittel für die Wandbefestigung ist das Trägermaterial auf Eignung zu prüfen. Montage mural: En cas de moyens de liaison pour la fixation murale, il faudra vérifier l'aptitude du matériel de support.
Seite 12
All manuals and user guides at all-guides.com M4x8 8 x SG1 GR 23 SG 1 SK 8 12 / 14...
Seite 13
All manuals and user guides at all-guides.com 13 / 14...
Seite 14
All manuals and user guides at all-guides.com FMD Möbel GmbH Heidländer Weg 68 D-49201 Dissen a.T.W. @ service@fmd-moebel.de +49 5421 9448-44 IAN 111183 14 / 14...
