Manual IB-M2HS-PS5 M.2 SSD Heat Sink for PlayStation ® Handbuch IB-M2HS-PS5 M.2 SSD Kühlkörper für PlayStation ®...
Seite 2
Safety information IB-M2HS-PS5 Please read carefully the following information to prevent injuries, damage to material and device as well as data loss: Warning levels Signal words and safety codes indicate the warning level and provide immediate information in terms of the probability of occurrence as well as the type and severity of the consequences if the measures to prevent hazards are not complied with.
Seite 3
Safety information IB-M2HS-PS5 • Do not modify the device • Do not connect the device during thunderstorms • Approach specialist retailers if you require repairs 2. Hazards during assembly (if intended) Sharp components CAUTION Potential injuries to fingers or hands during assembly (if intended) •...
Seite 4
Safety information IB-M2HS-PS5 • Always comply with the information in the operating instructions/quick installation guide • Exclusively use the product once the specifications have been met • Back up data prior to commissioning • Back up data prior to connecting new hardware •...
Sicherheitshinweise IB-M2HS-PS5 Zur Vermeidung körperlicher Schäden, sowie von Sach-, Geräte- schäden und Datenverlust beachten Sie bitte folgende Hinweise: Warnstufen Signalwort und Sicherheitszeichen kennzeichnen die Warnstufe und geben einen sofortigen Hinweis auf Wahrscheinlichkeit, Art und Schwere der Folgen, wenn die Maßnahmen zur Vermeidung der Gefahr nicht befolgt werden.
Seite 6
Sicherheitshinweise IB-M2HS-PS5 • Gerät nicht während eines Gewitters anschließen • Geben Sie Ihr Gerät im Reparaturfall in den Fachhandel 2. Gefahren während Montage (wenn vorgesehen) Scharfkantige Bauteile VORSICHT Finger- oder Handverletzungen bei Zusam- menbau (wenn vorgesehen) möglich • vor Montage, Betriebsanleitung lesen •...
Seite 7
Sicherheitshinweise IB-M2HS-PS5 • Produkt nur verwenden, wenn Spezifikationen erfüllt sind • Datensicherung vor Inbetriebnahme durchführen • Datensicherung vor Anschluss neuer Hardware durchführen • dem Produkt beiliegendes Zubehör verwenden 6. Reinigung des Gerätes Schädigende Reinigungsmittel ACHTUNG Kratzer, Farbveränderungen, Feuchteschäden oder Kurzschluss am Gerät •...
Manual IB-M2HS-PS5 Package content • 1x IB-M2HS-PS5 • 3x Thermal pad • 1x Set of screws • 1x Screwdriver • 1x Manual System requirements M.2 SSD 22x 80 mm Key features • M.2 SSD heat sink for PlayStation ® •...
Seite 9
Manual IB-M2HS-PS5 Place the first thermal pad on the frame. Pay attention to the semicircular notch at the end of the frame. Note: thick thermal pad for single-sided M.2 SSD, thin thermal pad for double-sided M.2 SSD! Gently press the M.2 SSD onto the thermal pad in the frame.
Seite 10
Manual IB-M2HS-PS5 Apply the second thermal pad to the top of your M.2 SSD. Press the heat sink onto the M.2 SSD. Make sure the direction of the heat sink is correct: the semicircular notch must line up with that of the frame.
Seite 11
Manual IB-M2HS-PS5 Tighten all four screws on the side. Press the heat Install the M.2 SSD with heat sink in your PS5 M.2 slot.
Handbuch IB-M2HS-PS5 Verpackungsinhalt • 1x IB-M2HS-PS5 • 3x Wärmeleitpad • 1x Schraubenset • 1x Schraubendreher • 1x Handbuch Systemanforderungen M.2 SSD 22x 80 mm Hauptmerkmale • M.2 SSD Kühlkörper für PlayStation ® • Für eine optimale Wärmeableitung Ihrer M.2 SSD •...
Seite 13
Handbuch IB-M2HS-PS5 Setzen Sie das erste Wärmeleitpad auf den Rahmen. Achten Sie dabei auf die halbrunde Kerbe am Ende des Rahmens. Hinweis: Dickes Wärmeleitpad für einseitig bestückte M.2 SSD, dünnes Wärmeleitpad für zweiseitig bestückte M.2 SSD! Drücken Sie die M.2 SSD vorsichtig auf das Wärmeleitpad im Rahmen.
Seite 14
Handbuch IB-M2HS-PS5 Bringen Sie das zweite Wärmeleitpad auf der Oberseite Ihrer M.2 SSD auf. Drücken Sie den Kühlkörper auf die M.2 SSD. Achten Sie dabei auf die richtige Richtung des Kühlkörpers: Die halbrunde Kerbe muss mit dem Rahmen übereinander passen.
Seite 15
Handbuch IB-M2HS-PS5 Ziehen Sie alle vier Schrauben an der Seite fest. Installieren Sie die M.2 SSD mit Kühlkörper in Ihrem PS5 M.2 Slot.
