Konformitätserklärung
We, MOBI-CLICK AG; Alte Steinhauserstrasse 19; CH-6330 Cham/ZG
declare under sole responsibility that the product:
M obi-Click Com pact
Mobile Phone and Security System
PCN 1800 MHz)
To which this declaration relates, is in conformity with the following essential requirements of the
Directive 1999/5/EC: Article 3.1 a), 3.1 b) and 3.2
The product has been tested against the following standards:
EN 301 511
Harmonised Standard for Mobile Stations in the GSM900/1800 Bands
EN 301 489-01
Electro Magnetic Compatibility Standard for Radio Equipment and Services
EN 301 489-07
Specific (EMC) Conditions for Mobile Radio Equipment, GSM 900/1800
EN 60950/IEC 950
Safety of Information Technology Equipment
EN 50360
Product Standard to demonstrate the Compliance of Mobile Phones with the Basic Restrictions related
to Human Exposure to Electromagnetic Fields
EN 50361
Basic Standard for the measurement of Specific Public to
The product is marked with the CE marking and Notified Body number according to the
Directive 1999/5/EC: Identification mark: CE
Place of Issue: Cham/ZG
40
(suitable for GSM/E-GSM 900 MHz and
Electromagnetic Fields
1471
Date of Issue: 01.03.2005
Temperaturbereich:
Arbeitsbereich mind. –10°C bis +55°C
Lagerbereich mind. –25°C bis +80°C
Gewicht:
78g (mit integriertem Akkumulator)
Abmessungen:
106 mm x 38 mm x 19 mm (LxBxH)
Betriebsspannung:
3,45 Volt bis 4,2 Volt (nominal 3,6 Volt)
Ladezyklus:
ca. 40 Min. (nach voll entladenem Akkumulator)
Standby-Zeit:
bis zu 290 Std. (Telefonmodus)
bis zu 200 Std. (Überwachungsmodus)
Modul:
Sagem M0110d
Batterie:
BAK 063448S2 Lithium Ion
Gesprächszeit:
bis zu 120 Min.
SIM-Karte:
3 Volt
Frequenzbänder:
EGSM900 (880 bis 960 MHz)
DCS1800 (1.710 bis 1.880 MHz)
GSM-Klassen:
Klasse 4 (2 Watt) bei EGSM900
Klasse 1 (1 Watt) bei DCS1800
Daten-Service:
SMS
Das Gerät arbeitet gemäss folgenden Standards:
GSM 03.03: "Digital cellular telecommunications system (Phase 2+); numbering, adressing and indentification". Version 6.6.0.
GSM 03.13: "Digital cellular telecommunications system (Phase 2+); Discontinuous Reception (DRX) in the GSM system". Version 6.0.0.
GSM 04.02: "Digital cellular telecommunications system (Phase 2+); GSM Public Land Mobile Network (PLMN) access reference configuration". Version 6.0.0.
GSM 04.03: "Digital cellular telecommunications system (Phase 2+); Mobile Station- Base Station System (MS-BSS) interface Channel structures and access capabilities". Version 6.0.0.
GSM 04.04: "Digital cellular telecommunications system (Phase 2+); Layer 1 General requirements". Version 6.0.0.
GSM 04.05: "Digital cellular telecommunications system (Phase 2+); Data Link (DL( layer General aspects". Version 6.0.1.
GSM 04.07: "Digital cellular telecommunications system (Phase 2+); Mobile radio interface signalling layer 3 General aspects". Version 6.5.1.
GSM 04.08: "Digital cellular telecommunications system (Phase 2+); Mobile radio interface layer 3 specification". Version 6.11.0.
Technische Daten
