All manuals and user guides at all-guides.com Handbuch CarCam one Vielen Dank, dass Sie sich für ein a-rival Produkt entschieden haben. Eine gute Wahl. Wir wünschen Ihnen viel Spaß. Im Falle eines Falles sind wir natürlich auch nach dem Kauf für Sie da. Bei technischen Fragen und/ oder Problemen erreichen Sie uns: per Telefon unter +49 (0)511 / 123 83 506, per e-Mail support@first-servicecenter.de oder auf http://a-rival.de/facebook/...
Seite 2
All manuals and user guides at all-guides.com Bitte lesen Sie diese Bedienungsanleitung aufmerksam bevor Sie dieses Gerät benutzen und bewahren Sie diese zum späteren Nachlesen gut auf. WICHTIGER HINWEIS: Abhörverbot Mit Ausnahme der Handlungen von Beamten der Strafverfolgungsbehörden, die im gesetz- lichen Auftrag handeln, ist es niemandem direkt oder indirekt gestattet, ein Gerät zu nutzen, um private Gespräche anderer abzuhören oder aufzuzeichnen, sofern dies nicht von allen am Gespräch beteiligten Parteien erlaubt wurde.
Seite 3
All manuals and user guides at all-guides.com den Verbrauch von Rohstoffen zu verringern! Trennen Sie Elektroschrott von anderen Abfällen und entsorgen Sie diese bitte über Ihr örtliches kostenloses Rücknahmesystem. Weitere Informationen zum Recycling erhalten Sie bei Ihrer Gemeindeverwaltung, den kommunalen Entsorgungsbetrieben, dem Geschäft in dem Sie das Produkt gekauft haben oder beim Hersteller.
Seite 4
All manuals and user guides at all-guides.com Materialrecycling hilft, den Verbrauch von Rohstoffen zu verringern! Trennen Sie Akkus von anderen Abfällen und entsorgen Sie diese bitte über Ihr örtliches kostenloses Altbatterie-Rücknahmesystem. Weitere Informationen zum Recycling erhalten Sie bei Ihrer Gemeindeverwaltung, den kommunalen Entsorgungsbetrieben, dem Geschäft in dem Sie das Produkt gekauft haben oder beim Hersteller.
All manuals and user guides at all-guides.com Aufbau des Produkts 1. Kamera 18. Lautsprecher LED
13. Einschub des Halters 11. Micro USB-Schnittstelle 15. Power-Anzeige 19. AV-Schnittstelle 5. MENU-Taste ...
All manuals and user guides at all-guides.com Aufladen des Akkus 1. Verbinden Sie das Ladegerät direkt mit der USB-Schnittstelle der Kamera. Der Ladevorgang wird auch bei ausgeschaltetem Gerät fortgesetzt. 2. USB-Aufladung: Die Aufladung erfolgt über ein USB-Kabel vom USB-Port des Computers zum USB-Port der Kamera.
All manuals and user guides at all-guides.com Einsetzen und Entfernen der TF-Karte 1. Bitte setzen Sie die TF-Karte in der angegebenen Richtung bis zum Anschlag in den Kartenslot ein. 2. Bitte üben sie beim Entnehmen der TF-Karte leichten Druck aus, bis diese ausgeworfen wird. Die Karte kann dann einfach entnommen werden.
Seite 8
All manuals and user guides at all-guides.com Benutzerhandbuch Starten und Beenden der Kamera Drücken Sie kurz die Power-Taste, um das Gerät zu starten; wenn Sie die Power-Taste gedrückt halten, schaltet sich das Gerät aus. Wenn die TF-Karte eingesetzt und dann die Verbindung zum Kfz-Ladegerät hergestellt wird, startet das Gerät und beginnt automatisch mit der Aufnahme.
Seite 9
All manuals and user guides at all-guides.com Date/Time (Datum/Uhrzeit): Hier kann Datum und Uhrzeit eingegeben werden Tastenton: Der Tastenton kann hier ein- oder ausgeschaltet werden Spracheinstellung: Einstellung der gewünschten Sprache TV-Modus: Einstellung von NTSC / PAL Frequenz: Wahl zwischen 50 HZ/60 HZ (aktuelle Frequenz) Bildschirmschoner: Hier kann der Bildschirmschoner eingestellt werden LED: Ein- oder Ausschalten der Front LED Kennzeichen: Eingabe des KFZ Kennzeichens.
All manuals and user guides at all-guides.com Aufnahmeverfahren und Einstellungen der Aufnahmeoptionen Aufnahme Wenn sich Gerät Aufnahmemodus befindet entsprechende Symbol in der linken oberen Ecke erscheint, drücken Sie die Taste OK, um die Aufnahme zu starten. Während die Aufnahme läuft blinkt das Symbol in der oberen linken Ecke.
Seite 11
All manuals and user guides at all-guides.com Auflösung: Es kann zwischen den folgenden Werten gewählt werden: 1080HFD/720P-60 FPS/720-30FPS/WVGA/VGA Loop-Aufnahme: Aus/2min/3min/5min für die Option G-Sensor Aufnahme: 1min / 3 min / 5min. Wenn G-Sensor auslöst, wird die Aufnahme gestartet. WDR: immer an Belichtung: +2,0;...
All manuals and user guides at all-guides.com Fotografieren und Einstellungen: 1. Nach dem Starten des Gerätes drücken Sie die Mode-Taste, um in den Fotografieren-Modus zu gelangen. Wenn das Symbol in der oberen linken Ecke angezeigt wird, befindet sich das Gerät im Fotografie-Modus. 2.
Seite 13
All manuals and user guides at all-guides.com Schärfe: Scharf / normal / weich Weißabgleich: Automatisch / Tageslicht / Bewölkter Tag / Wolfram-Lampe / Leuchtstofflampe Farbe: Bunt / weiß und schwarz / Sepia ISO: Automatik/100/200/400 Belichtung: +2,0; +5/3, +4/3; +1,0; +2/3; 1/3; 0,0; -1/3; -2/3; -1,0; -4/3; -5/3; -2,0 Bildstabilisator: Aus / An Datumsanzeige: Aus, Datum und Uhrzeit für die Option Wiedergabemodus:...
Seite 14
All manuals and user guides at all-guides.com Bilddaten AV-Material zugreifen. AV-Material erscheint Symbol in der oberen rechten Ecke des Bildschirms; wenn Sie die OK-Taste drücken, können Sie das Abspielen des AV-Materials starten oder stoppen. Während der Wiedergabe können Sie durch Drücken der Pfeiltasten die Lautstärke erhöhen oder verringern. Wird ein Bild angezeigt, erscheint das Symbol in der oberen rechten Ecke des Bildschirms;...
All manuals and user guides at all-guides.com Aufladen während der Aufnahme Wenn das Gerät mittels USB-Kabel an die Stromversorgung des Kraftfahrzeugs angeschlossen wird, geht das Gerät in den Betriebszustand des Aufladens bei gleichzeitiger Aufnahme über. Datensicherung USB-Backup-Modus: Verbinden Sie das Gerät per USB-Kabel mit einem Computer; das Gerät startet dann automatisch. Es erscheint folgende Meldung: Massenspeicher oder PC-Kamera.
All manuals and user guides at all-guides.com Bemerkung: 1. Betriebssystem des Computers: Windows XP / Windows 7 oder höher. 2. Wählen Sie Kamera; diese kann dann als Computer-Kamera verwendet werden. 3. Nach dem Entfernen des USB-Kabels, schaltet sich das Gerät automatisch aus. Abspielen auf einem Fernsehgerät 1.
All manuals and user guides at all-guides.com Garantieerklärung Bitte verwahren Sie den Kaufbeleg für dieses Gerät für die Dauer der Garantie auf, da er bei einer eventuellen Reklamation beigefügt werden muss. Sie (der Endverbraucher) erhalten 36 Monate Garantie mit Beginn des Verkaufsdatums. Der Artikel wurde unter Anwendung modernster Herstellungsverfahren gefertigt und strengen Qualitätskontrollen unterzogen.
Hiermit erklärt die Baros GmbH, dass sich das Gerät Car Cam One/CQN6O in Übereinstimmung mit den grundlegenden Anforderungen und den übrigen einschlägigen Bestimmungen der Richtlinie 1999/5/EG befindet. Die Konformitätserklärung kann unter folgender Adresse gefunden werden: www.a-rival.de Kundenservice/Kontakt Sollte Ihr Gerät einen Defekt aufweisen/Sie ein Problem damit haben, schicken Sie uns das Gerät bitte unter Berücksichtigung der folgenden Punkte an die unten stehende Adresse.
Seite 21
All manuals and user guides at all-guides.com Manual CarCam one Thank you for choosing an a-rival product. A good choice. Just in case that you are facing any problems with your device, please call our support/service hotline +49 (0)511 / 123 83 506, send us an e-mail to support@first-servicecenter.de or visit us on http://a-rival.de/facebook/...
Seite 22
All manuals and user guides at all-guides.com Please read this manual carefully before you use this unit, and keep it well for further checking. IMPORTANT NOTE: Prohibition against eavesdropping Except for the operations of law enforcement officers conducted under lawful authority, no one permitted directly or indirectly a device operated pursuant to the provisions of this Part for the purpose of overhearing or recording the private conversations of others unless such use is authorized by all of the parties engaging in the conversation.
Seite 23
All manuals and user guides at all-guides.com Important info for disposal of batteries (applicable in the countries of the European Union and other European countries with separate battery collection systems) On the battery, the packaging or accompanying manuals for the product, the symbol of the crossed out wheeled bin indicates that the batteries in this product should not be disposed of with normal household waste! The chemical symbols for lead (Pb) ,mercury (Hg) and Cd below the crossed out...
All manuals and user guides at all-guides.com Battery Charging 1. Connect the car charger directly with camera USB interface. Charge will continue even if it is shut down. 2. USB charge: By connecting the USB data line with computer and the other end with camera. Charge will continue even if it is shut down.
Seite 26
All manuals and user guides at all-guides.com Insertion and Withdrawal of Micro SD Card 1. Please insert the Micro SD card into card slot according to the indicated direction until it is fixed. 2. While withdrawing, please press the Micro SD card lightly till it is ejected out and then take it out. Notes: 1.
Seite 27
All manuals and user guides at all-guides.com User Manual 1. Start and close of driving recorder Press the power key shortly to start; while it is on, long press the power key to close it. Insertion of Micro SD card first and then connecting with car charger will start the machine and recording automatically.
Seite 28
All manuals and user guides at all-guides.com Date/Time: Which can adjust current date and time Beep Sound: Choose ON or OFF. Language Setting: Choose language according to the requirements. TV Mode: Which can set NTSC/PAL Frequency: Which can choose 50HZ/60HZ (current frequency) Screen Saver: Which can save screen protection LED: Set the light on or off Car Plate: Type your Car Plate.
Seite 29
All manuals and user guides at all-guides.com Recording Method and Settings of Record Options 1. Recording When the machine is in the mode of recording, if there is a symbol in top left corner, press OK key to start recording. While recording, the symbol in top left corner starts to flash.
Seite 30
All manuals and user guides at all-guides.com Reminder: In the recording in the state of low power, there might be abnormal blurred images or auto-closing; therefore, connect the car charger and close the machine for a while when it is charging.
All manuals and user guides at all-guides.com White Balance: Automatic/Daylight/Cloudy day/ Tungsten Lamp/Fluorescent Lamp Color: Colorful/White and Black/ Sepia ISO: Automatic/100/200/400 Exposure: +2.0, +5/3, +4/3, +1.0, +2/3, +1/3, +0.0, -1/3, -2/3, -1.0, -4/3, -5/3, -2.0 Anti-shake: On/Off Date Tag: Off, Date and Time for option Playback Mode: 1.
Seite 32
All manuals and user guides at all-guides.com single picture mode; at this time, you can operate the image and audiovisual materials. If it is audiovisual material, there will be a symbol in top right corner of the screen; press OK key to play or pause the audiovisual material.
All manuals and user guides at all-guides.com Charging while Recording Connect the USB interface of machine with car charger, and the mode of charging while recording is on after starting the machine. Data Backup USB backup mode: Connect the machine and computer with USB cable and the machine will be started automatically. The following note will show up: Mass storage or PC camera.
Seite 34
All manuals and user guides at all-guides.com Remark: 1. Operating system of computer: Windows XP/ Windows 7 or above 2. Choose camera, which can be used as computer camera. 3. After removal of USB cable, the machine will close automatically. Play on TV 1.
All manuals and user guides at all-guides.com Technical Specifications Master control Nt96650 Platform DV Turnkey DDR3 1GB Anti-shake technology Support Digital Magnification Factor 4 times Recording Resolution Ratio 1080FHD 1920X1080 720P 1280X720 WVGA 848X480; VGA 640X480 File Format Picture: JPG; Video: MOV Wide Dynamic Range(WDR) Support Color Effect...
Seite 36
All manuals and user guides at all-guides.com Motion Detection Function Support Y/M/D/H/Minute Support Media Vehicle Micro SD Card (support 32GB at most) HDMI Interface Support Av Interface Support System NTSC/PAL USB Function Memory Camera...
Seite 37
All manuals and user guides at all-guides.com Guarantee Please keep the proof of purchase for this device for the entire duration of the guarantee period, as it must be produced in the event of any claim. You (as the end user) receive a 36-month guarantee from the date of sale. The article has been manufactured using the most modern production methods and subjected to strict quality controls.
Hereby Baros GmbH declares, that the device One/CQN6O is in compliance with the essential requirements and other relevant regulations of Directive 1999/5/EC. The Declaration of Conformity can be found at: www.a-rival.de User information/Contact If your device has a defect or you have problems with it, please contact our Service & Support Centre.
