Remote control:

INPUT Select Radio - USB - SD - AUX
Radio mode:
CH--/ CH+ Search Back and Forward
PREV / NEXT Previous / Next Program
PLAY / PAUSE NB: A long press for scanning and storing radio stations in program.
VOL-- / VOL+ Volume Down and Up (only when switch is in MP / Aux state)
EQ Does not function in radio mode
STOP mode In Radio mode no function
REPEAT No function in radio mode
0 to 9 Direct Select program location
USB en SD Mode :
CH-/ CH + No function in state USB or SD
PREV / NEXT Previous or next track
PLAY / PAUSE Play - Pause - Play - Pause - etc.
VOL-/ VOL + Volume Down and Up (only when switch is in MP / Aux state)
EQ Choose Equalizer from E0 to E6
STOP Stops playing
REPEAT Will Repeat ALL - Folder - One or Random-positions
0 – 9 Direct dialling
Battery: CR2025 (included)
Remove plastic strip on the bottom.
Aux-mode :
Use in this mode only the "INPUT" button on the remote control.

SPECIFICATIONS

Max Output Power @
4 Ohm
Max Output Power @
8 Ohm
Load Impedance
minimum
Input
Connectors
Output
Input Sensitivity
Input Impedance
Frequency Response
THD +N
Signal to Noise Ratio.
Cross-talk
Indicators
Mains Power
Fuses
Dimension(W X D X H)
Weight
SPL–MP3 SERIES
SPL SPL
500EQ 700EQ
2x 250W 2x 350W
2x 200W 2x 250W
6x RCA (phono) socket & 3.5mm Stereo Jack
220~240 Vac(Euro) / 50 Hz
T1A
4,2kg
3,5kg
- 5 -
SPL
1000EQ 1500EQ
2x 500W 2x 750W
2x 350W 2x 500W
4 Ohm
Speaker terminal board
775 mV
10 K min.
20 Hz - 20 KHz ±3 dB
< 0.5 %
>95 dB
> 82dB at 1KHz
Clip / Signal / Power
T2A T4A
482 X 290 X 88mm
4,8kg
SPL SPL
2000EQ
2x 1000W
2x 750W
T4A
5,4kg 6kg
