Additional safety instructions for batteries
• Never attempt to open for any reason.
• Do not store in locations where the temperature may exceed 40 °C.
• Charge only at ambient temperatures between 4 °C and 40 °C.
• Charge only using the charger provided with the tool.
• When disposing of batteries, follow the instructions given in the
section "RECYCLING".
• Do not cause short circuits. If connection is made between the positive
(+) and negative (-) terminal directly or via accidental contact with
metallic objects, the battery is short circuited and an intense current
will flow causing heat generation which may lead to casing rupture or
fire.
• Do not heat. If batteries are heated to above 100 °C, sealing and
insulating separators and other polymer components may be
damaged resulting in electrolyte leakage and/or internal short
circuiting leading to heat generation causing rupture or file. Moreover
do not dispose of the batteries in fire, explosion and/or intense burning
may result.
• Under extreme conditions, battery leakage may occur. When you
notice liquid on the battery, proceed as follows:
• Carefully wipe the liquid off using a cloth. Avoid skin contact.
• In case of skin or eye contact, follow the instructions below:
• Immediately rinse with water. Neutralize with a mild acid such as
lemon juice or vinegar.
• In case of eye contact, rinse abundantly with clean water for at least
10 minutes. Consult a physician.
Fire hazard! Avoid short-circuiting the contacts of a detached
battery. Do not incinerate the battery.
Additional safety instructions for chargers
• Use the charger provided with the tool only to charge the battery
• Never attempt to charge non-rechargeable batteries.
• Have defective cords replaced immediately.
• Do not expose to water.
• Do not open the charger.
• Do not probe the charger.
• The charger is intended for indoor use only.
Explanation of symbols
The rating plate on your tool may show certain symbols. These represent
information about the product or instructions on its use.
Conforms to relevant safety standards.
To reduce the risk of injury, user must read
instruction manual.
Do not dispose of old appliances with domestic
rubbish.
Only use in closed rooms.
Separate collection symbol - Battery with heavy
metal element
"Li-ion".
TECHNICAL PARAMETERS
Voltage
Preheat time
Lithium battery
Glue stick D.M.
Adapter output
Charging time
DESCRIPTION
The cordless hot glue gun is ideal for gluing wood, glass and metals, it
also features a built-in stand to keep the gun off flat surfaces. The compact
size makes storage easy.
Figure 1
1. Nozzle
2. Heating indicator
3. Charging port
4. Switch button
4V DC
25 s
Li-ion 3.7V 2200 mAh
Ø11 mm
5V DC, 1000 mA
2-3 hours
5. Charging and power indicator
6. Glue stick inlet
7. Soft handle
8. Trigger
9. Removable stand
EQUIPMENT AND ACCESSORIES
1. USB charging cable
2. Glue 2 pcs.
BEFORE FIRST USE
Note: Before first use, the hot glue gun must be awakened by connecting
the adapter to the power supply, the indicator (5) shows red, the tool can
be used normally after unplugging the adapter.
How to recharge the glue gun
Note: During charging the battery will become warm as it is being charged.
First read the safety instructions then follow the charging instructions.
Plug the charging plug (11) into the charging port (3) on the top of this glue
gun.
Charge time is approximately 2-3 hours.
When the battery is charging, the RED indicator (5) keeps illuminate.
When fully charged, the indicator (5) will become green until unplug the
adapter (10) from the mains socket, the glue gun is ready to use.
Note: Do not allow the cable to become knotted or kinked. This adapter
and product are specifically designed to work together. Do not attempt to
use any other brand of cordless tool or battery pack with this adapter.
Avoid charging your battery in freezing conditions as charging power will
not be sufficient.
If the tool will not be used for long periods of time, charge the battery every
3-6 months. To prevent damage to the battery, when charge runs out,
charge the battery to reach full or no less than half charge before storage.
HOW TO USE THE GLUE GUN
1. Insert a glue stick inlet of the gun (Fig. 2).
2.Press the switch button and hold on for 1-2 seconds,then, the glue gun
will be in the " ON "position,also,press the button and hold on for 1-2
seconds,which will be in "OFF" position (4), the heating indicator (2) and
indicator (5) lights. Use the removable stand (9) and rest the gun on a
stable flat surface. The removable stand can be pushed back when in use
(Fig. 3 and 4).
Note: No Red
showing (5), in the fact, it will always be shown in
the green color
once the glue gun powered on (4).
3. Allow the gun to heat up,
4. Before starting to use the glue gun, ensure all surfaces to be glued are
clean and dry.
5. Press the trigger (8) until the glue starts to flow from the nozzle (1).
6. Apply the glue to one surface. Press the surfaces together and hold for
15-20 s.
7. After use, switch off: press and hold the switch (4) for 1 s and all
indicators (2 and 5) extinguishes. The glue gun switches off automatically
after 10 minutes in order to save energy.
RELEASING/SETTING SHIPPING MODE
This tool is preset to shipping mode (dormant state) to avoid discharging
the battery due to misoperation, so the switch cannot start the tool. Before
first use, the hot glue gun must be awakened by connecting the adapter to
the power supply, the indicator (5) shows red, the tool can be used
normally after unplug the adapter.
It is recommended to reset the tool to shipping mode when in transport or
storage. Press and hold the switch button (4) 8-10 s, release it after the red
indicator (5) flashes 3 times and make sure that the switch does not work.
CLEANING AND MAINTENANCE
1. Always allow the appliance to cool off after use.
2. Clean the appliance with dry cloth.
3. If you don't want to use this appliance for a period of time, store it on a
dry and well ventilated place. Keep it out of reach of children.
4. Machines should be far away from corrosive substances: fire, water,
benzene.
RECYCLING
Do not dispose of electrical appliances as unsorted
municipal waste, use separate collection facilities. Contact
you local government for information regarding the
collection systems available. If electrical appliances are
disposed of in landfills or dumps, hazardous substances
can leak into the groundwater and get into the food chain,
damaging your health and well-being.
Bedienungsanleitung
Akku-Heißklebepistole
Red: Operation after preheating 25 s.
