Step 4: The tom arm (16) needs to be inserted
into the tom arm bracket which is on the top of
the bass drum.
Step 5: For the floor tom (7), please place the
black rim (9) on the head (8) of the drum, then
insert the tension rods (10) with drum key (28)
thru the holes of the rim and into the lugs on the
drum. Repeat above steps for tom toms
(12&17).
Step 6: With the floor tom sitting upside down,
insert the three floor tom legs (11) thru the
brackets and tighten them in using the T-handle.
