FM radio
antenna plug
iPod video
output
Optical digital
input (Digi 1)
Coaxial digital
input (Digi 2)
Speaker output
(white connector)
Step 4: Put your audio/video equipment, such as set top box, DVD/Blueray player or
game console into the compartment on the right. Put your TV set on top. Connect your
equipment with the rear panel of the Geneva Sound System on either Line1, Line 2 or
Line 3 (see picture above).
Line in
Infrared output
Jacks
Speaker output
(black connector)
19
AIR-Connector
(for future use)
Fuse
AC Connector
