Parts and description

JBL PROFLORA CO₂ CONTROL measuring and display unit
1
Power supply unit 12 V DC
2
Temperature sensor
3
Connecting cable for solenoid valve
4
Suction holder for temperature sensor (2 x)
5
Top-hat rail
6
Screws with dowels (2 x each)
7
Holder for calibration cuvettes
8
JBL PROFLORA CO₂ pH SENSOR SET (please purchase separately!)
!
Installation
The illustration (Page 4) shows a typical installation example.
Measuring and control device JBL PROFLORA CO₂ CONTROL
1
Coloured touch display
A
Input socket for power supply 12 V DC
B
Input socket for temperature sensor
C
BNC connection for pH sensor
D
12 V DC output socket for connecting cable for solenoid valve
E
Power supply unit 12 V DC
2
Temperature sensor
3
Connecting cable for solenoid valve
4
JBL PROFLORA CO₂ pH SENSOR SET
9
reactor JBL PROFLORA CO₂ TAIFUN SPIRAL
CO
10
2
Bubble counter with integrated backflow protection JBL PROFLORA CO₂ TAIFUN COUNT SAFE
11
Solenoid valve JBL PROFLORA CO₂ VALVE
12
JBL PROFLORA CO₂ TAIFUN TUBE BLACK Special CO
13
JBL PROAQUATEST CO
14
-pH Permanent
2
hose
2
