Seite 2
Inhalt | Content Bedienungsanleitung CONNECT People Counter ..User manual CONNECT People Counter ......Manuale utente CONNECT People Counter .....
Seite 3
Sie dieses zunächst über unsere CONNECT App mit dem Netzwerk verbinden. Dort finden Sie auch weitere Anweisungen zur Bedienung. Zum App-Download gelangen Sie entweder durch Einscannen des QR-Codes auf der Rück- seite dieser Anleitung oder durch die Suche nach „ratiotec CONNECT“ im Google Play Store.
Sicherheits- und Wartungshinweise: Bitte prüfen Sie den Verpackungsinhalt genau. Sollte etwas fehlen oder durch den Transport beschädigt sein, dürfen Sie das Gerät nicht in Betrieb nehmen. Verwenden Sie nur die angegebenen Netzteile und/oder Batterien. Inbetriebnahme Überprüfen Sie vor dem Gebrauch die Batterien/micro-USB Netzkabel, auf Beschädigungen (nicht im Lieferumfang ent- halten).
Montage Die Personenzähler müssen direkt aufeinander ausgerichtet sein. Receiver Transmitter Es gibt 4 Möglichkeiten der Anbringung der Personenzähler. Der Hersteller bietet zur Montage ein Kugelhalterungsset, ein Winkel Set und ein Set mit einer Bodenplatte an. Sie können alternativ das Gehäuse aber auch direkt an die Wand schrauben.
Seite 6
Eine halbe Drehung des Empfängers invertiert die Richtungs- erkennung des CONNECT Personenzählers. Besonders zu beachten ist, dass die Montagehöhe niedrig genug sein muss, um alle relevanten Personen erfassen zu können. Sie muss jedoch auch hoch genug sein, um regelmäßige, zusätz- liche Objekte wie Einkaufswagen und Kinderwagen nicht zu erfassen.
Warnung: Direkte Sonneneinstrahlung auf den Empfänger ist zu vermeiden! Receiver Technische Daten Spannung: Micro USB = 5V Batterie = 3,6 Volt Laufzeit = bis zu 5 Monaten mit 2x 19.000mAh Batterien...
Seite 8
Receiver Transmitter In order to use the CONNECT People Counter, you first have to connect it to the network via our CONNECT app. In the app you will also find further information about the opera- tion. You can download the app either by scanning the QR code on the back of this instruction manual or by searching for „ratiotec CONNECT“...
Check the batteries / micro-USB power cables for damage before use (not included in the delivery). Open the lower housing of the CONNECT People Counter to be able to insert the batteries. Make sure that the batteries are inserted as shown in the drawing below.
Seite 10
Mounting The CONNECT People Counters must be directly aligned with each other. Receiver Transmitter There are four ways of mounting the CONNECT People Counters. The manufacturer offers a ball holder set, an angle set and a set with a base plate for mounting. Alternative- ly, you can also screw the housing directly onto the wall.
Seite 11
Half a rotation of the receiver inverts the direction detection of the CONNECT personal counter. It is particularly important to note that the installation height must be low enough to be able to record all relevant persons. However, it must also be high enough not to detect regular, additional objects such as shopping carts and baby strollers.
Warning: Direct sunlight on the receiver is to be avoided! Receiver Technical data Voltage: micro USB = 5 V battery = 3,6 Volt Runtime = up to 5 months with 2x 19. 000 mAh batteries...
Seite 13
Per utilizzare CONNECT conta persone, devi prima connet- terlo alla rete tramite la nostra app CONNECT. Nell‘app tro- verai anche ulteriori informazioni sull‘operazione. È possibile scaricare l‘app scansionando il codice QR sul retro di questo manuale di istruzioni o cercando „ratiotec CONNECT“ nel Google Play Store.
Informazioni sulla sicurezza e sulla manutenzione Si prega di controllare attentamente il contenuto della con- fezione. Se qualcosa manca o è stato danneggiato durante il trasporto, non mettere in funzione il dispositivo. Installazione Erificare che le batterie / il cavo di alimentazione micro-USB non siano danneggiati prima dell‘uso (non incluso nella conse- gna).
Seite 15
Montaggio I contatori di persone devono essere allineati direttamente tra loro. Receiver Transmitter Esistono 4 modi per collegare il contatore persone. Il produt- tore offre un set di supporti per sfere, un set di angoli e un set con una piastra di base per il montaggio. In alternativa, è possibile avvitare l‘alloggiamento direttamente sulla parete.
Seite 16
Mezzo giro del ricevitore inverte il rilevamento della direzione del contatore di persone CONNECT. È particolarmente importante notare che l‘altezza di installazione deve essere abbastanza bassa da essere in grado di catturare tutte le persone interessate. Tuttavia, deve anche essere abbastanza alto da non registrare oggetti aggiuntivi regolari come carrelli della spesa e carrozzine.
Attenzione: Evitare la luce solare diretta sul ricevitore! Receiver Dati tecnici Tensione: Micro USB - Batteria 5V - 3.6 Volt Tempo di esecuzione fino a 5 mesi con batterie 2x 19.000mAh...
Seite 19
Umweltschutz zu unterstützen und dieses Gerät zur Entsorgung an uns zurückzusenden: ratiotec GmbH & Co. KG, Max-Keith-Str. 66, 45136 Essen, Deutschland -EN- This equipment is marked with the above recycling symbol. It means that at the end of the life of the equipment you must dispose of it separately and not place it in the normal domestic unsorted waste stream.
Seite 20
GmbH & Co. KG Scan the QR code or search Max-Keith-Str. 66 | 45136 Essen ratiotec CONNECT in the T: +49 (0) 201-36149 – 1 Google Play Store. F: +49 (0) 201/361 49 – 26 www.ratiotec-connect.com connect@ratio-tec.de...
