Installation; Specification; Warranty - Natec ALFAMA Bedienungsanleitung

INSTALLATION

1. Unfold the tripod and attach the
ball head on the top.
2. Screw the ring to the ball head,
then attach the smartphone
holder in the centre of the ring.
3. Plug the device in to a USB port.
REMOTE
1,7 - On/Off
2,3 – Bright switch
4 – Cold light temperature
5 – Neutral light temperature
6 – Warm light temperature
8 – Demo mode
9,10 – Mode switch
11,12 – Speed control
13,14 – Bright switch
15 – Lock lighting effect
16 – Back to white light
17 – Temporary lighting effect lock
18 – Solid red light
19 – Solid green light
20 – Solid blue light
WIRELESS CONNECTION
• Enable the Bluetooth functionality of the device you wish to
pair with the selfie remote.
• Slide the side button on the selfie remote upwards. The LED
will flash, indicating that it was turned on.
• From the displayed on your device, select the "AB Shutter 3"
selfie remote.
• The LED on the remote will turn off.
• From now on, pairing will occur automatically when both
devices are within range.
REQUIREMENTS
• PC or compatible device with a USB port
• Bluetooth 4.0
SAFETY INFORMATION
• Use as intended.
• Non-authorized repairs or disassembly voids the warranty and
may damage the product.
• Dropping or hitting the device may lead to device being
damaged, scratched or flawed in other way.
• Do not use the product in low and high temperatures, strong
magnetic fields and damp or dusty surroundings.
• Improper usage may break the device.
• Slots and openings in the case are provided for ventilation and
should not be obscured. Blocking the vents can cause
overheating of the device.
• People exposed to flashing lights may experience epileptic
seizures or other symptoms of epilepsy. If you experience
convulsions, dizziness or abnormal perception of any kind,
please contact your doctor immediately.
1.
8 13
3
6
2 5
11
1
4
7 9

SPECIFICATION

• Lamp size
• Number of LEDs
• Color temperature
• Lumens
• CRI
• Lamp angle adjustment
• Power
• Connector
• Communication (selfie remote)
• Cable length
• Tripod height

WARRANTY

• 2 years limited manufacturer warranty.
GENERAL
• The safe product, conforming to the EU requirements.
• The product is made in accordance with RoHS European
standard.
• The WEEE symbol (the crossed-out wheeled bin) using
indicates that this product in not home waste. Appropriate
waste management aids in avoiding consequences which are
harmful for people and environment and result from dangerous
materials used in the device, as well as improper storage and
processing. Segregated household waste collection aids
recycle materials and components of which the device was
made. In order to get detailed information about recycling this
product please contact your retailer or a local authority.
• Hereby, IMPAKT S.A. declares that that the radio equipment
type NLL-1833 is in compliance with Directives 2014/53/UE
(RED) and 2011/65/UE (ROHS). The full text of the EU
declaration of conformity is available via the product tab at
www.impakt.com.pl.
2.
14 17
20
19
18
10 15
12 16
3.
PACKAGE CONTENT
• Natec Alfama RGB Ring Light
• Ball head
• Smartphone holder
• Tripod
• Lighting remote
• Selfie remote
• User guide
10''
168 pcs
3000 – 6500 K
800 lm
>85 Ra
Yes
10 W
USB (5V DC)
BT 4.0
200 cm
19 cm
EN
