Series PMT2 Particulate Transmitter
The Particulate Transmitter is designed to measure particulate emission
levels from dust collector discharge. Using DC coupled electrostatic induction sensing
technology, the transmitter monitors a pA current that is generated as particulate
passes near the probe; a 4-20 mA signal will vary based on the particulate level. The
the application. The range and test selector switch can also be set to output a 4 mA or
20 mA signal to assist with set up or trouble shooting. Averaging time setting can be
used to dampen the signal if desired.
• Simple 2-wire installation for PLC and control panels
• Non-stick PTFE coated probe to prevent false readings from moist and conductive
dusts, condensate, and dust buildup
• Remote zero calibration helps to decrease maintenance time
Example PMT2
Series PMT2
03
05
10
15
20
30
36
A
B
C
A2
U2
compliant. These Units are not intended for use in potentially hazardous
atmospheres in the EU. These unites may be CE marked for other Directives
of the EU.
2X 1/2˝ NPT OR M20 ELECTRICAL ENTRY
A
in [mm]
3 [76.20]
5 [127.00]
5/8
10 [254.00] [15.88]
15 [381.00]
20 [508.00]
30 [762.00]
36 [914.40]
A B
in [mm] in [mm]
3-1/2 [88.90] 1-25/32 [45.24]
5-1/2 [139.70] 3-25/32 [96.04]
10-1/2 [266.70] 8-25/32 [223.04]
15-1/2 [393.70] 13-25/32 [350.04]
20-1/2 [520.70] 18-25/32 [477.04]
30-1/2 [744.70] 28-25/32 [731.04]
36-1/2 [927.10] 34-25/32 [883.44]
Particulate transmitter
UL (IS)*
ST Stainless steel tag
M2 Female M20 electrical entries
3/4˝ NPT or 3/4˝ BSPT
"A"
3/4
[19.05]
1-1/2
[38.10]
4-15/16
[125.41]
2X 1/2˝ NPT OR M20 ELECTRICAL ENTRY
1˝ NPT
"B"
5-13/16
"A"
[147.64]
Service: Air and compatible gases, any type of particulate conductive or non-
conductive.
316L SS, silicone, and PTFE.
Powder coated aluminum.
Accuracy: ±5% of reading.
Particulate Size: 0.3 microns and higher.
5 to 5000 pA (6 selectable range options).
Temperature Limits: Ambient: -40 to 145°F (-40 to 63°C); Process: -40 to 248°F
(-40 to 120°C).
Pressure Limit: 30 psi (2 bar).
4-20 mA.
12-28 VDC (
Removable (16 to 20 AWG wire).
See model chart. BSPT process connections are not UL
listed.
See model chart.
1 to 360 s (10 selectable options).
Varies with length of probe and type of mount.
16ATEX1768 X. ATEX Standards: EN 60079-0:2012/A11:2013; EN 60079-11:2012.
IEC 60079-11: 2011. UL Listed Intrinsically Safe for Class I, Groups C and D; Class
ia IIB T4 Ga.
3-29/32
[99.22]
3-29/32
[99.22]
).
Any.
Process
Process
Process
ALLOW 1-1/4˝ [32]
FOR COVER REMOVAL
BOTH SIDES
4-3/8
[111.13]
Process
