THANK YOU FOR PURCHASING
THE MACHIAVELLI MkII STEREO
CARTRIDGE.
PACKAGE CONTENT
|
Cartridge body
|
Set of head-shell fixing 2,5mm screws
(non-magnetic)
|
2mm Allen Wrench
|
User Manual
MACHIAVELLI MkII GOLD
Output level
0.4mV
Frequency response
10 - 40000Hz
Impedance
30Ω
Compliance
10×10-6cm/dyne
Channel separation
>28dB
Cantilever
Boron
Diamond
Line Contact
MACHIAVELLI MkII RED
Output level
0.5mV
Frequency response
10 - 40000Hz
Impedance
40Ω
Compliance
10×10-6cm/dyne
Channel separation
>28dB
Cantilever
Aluminium
Diamond
Micro Elliptical
MC Low Output
Diamond size
5×20µm
Coil Wire
Copper
Magnet
Samarium-Cobalt
Hole-diamond distance
9mm
Total weight
10g
Body
Duralumin 7000 alloy
MC Low Output
Diamond size
7.5×15µm
Coil Wire
Copper
Magnet
Samarium-Cobalt
Hole-diamond distance
9mm
Total weight
10g
Body
Duralumin 7000 alloy
BEFORE USING
1 The stylus is very delicate and applying excessive
force to the stylus, such as finger pressure, can
result in damages. Handle the cartridge with the
utmost care.
2 A powerful magnet is used in the cartridge.
Operating steel/magnetic tools or similar items
near the cartridge will exert a force on the
magnet and may result in damages to the stylus
and the cartridge.
MACHIAVELLI MkII
The Machiavelli MkII is one of our highest performing
low output MC phono cartridges, developed with the
sole purpose to let you enjoy your vinyl records at the
best.
Both the Machiavelli Gold and Red are engineered
around their diamonds, which have been developed
exclusively with Ogura, one of the world's most famous
professional diamond manufacturers. The body of the
Machiavelli is extremely light, with a weight of just 10
grams, and stiff to minimise unwanted vibrations - such
qualities ensure superb tracking ability. The Machiavelli
also benefits from the special design of the cantilever
suspension, made of elastic non-deformable harmonic
steel that's firmly locked in position.
Completing the design of the Machiavelli, the thin
and long gold-plated pin connectors provide the ideal
surface of contact with the arm cinches, resulting in
better grounding for a more silent music background
and the extraction of finer details.
The Machiavelli Gold features an exclusive cantilever
made in Boron and a Line Contact diamond. The
Machiavelli Red features an ultra-rigid cantilever made
in Aluminium and a Micro Elliptical diamond.
Thanks to the high internal impedance levels and
output levels, both Machiavelli Gold and Red can be
easily matched with any active MM and MC phono
preamp correctly set up without the need of Step-Up
transformers.
Werbung
Inhaltszusammenfassung für Gold Note MACHIAVELLI MkII STEREO
- Seite 1 THANK YOU FOR PURCHASING THE MACHIAVELLI MkII STEREO CARTRIDGE. PACKAGE CONTENT BEFORE USING 1 The stylus is very delicate and applying excessive Cartridge body force to the stylus, such as finger pressure, can Set of head-shell fixing 2,5mm screws result in damages. Handle the cartridge with the (non-magnetic) utmost care.
- Seite 2 25,9mm 12,7mm 11mm 4,2mm 18mm 9,8mm 19,1mm SET-UP Mount the cartridge on the tonearm head-shell using Fig.1 the supplied Allen Wrench and one set of the 2,5mm screws. Adjust it to the stylus position suggested for x2 x2 your turntable system (see Fig.1). The output terminals are colour coded for ease of use (see Fig.2).
-
Seite 3: Vor Dem Gebrauch
VIELEN DANK, DASS SIE VIELEN DANK, DASS SIE SICH FÜR DAS MACHIAVELLI SICH FÜR DAS MACHIAVELLI MkII TONABNEHMERSYSTEM MkII TONABNEHMERSYSTEM ENTSCHIEDEN HABEN. ENTSCHIEDEN HABEN. PACKUNGSINHALT PACKUNGSINHALT VOR DEM GEBRAUCH VOR DEM GEBRAUCH 1 Die Tonnadel ist sehr empfindlich und das 1 Die Tonnadel ist sehr empfindlich und das Tonabnehmersystem Tonabnehmersystem... -
Seite 4: Montage
25,9mm 12,7mm 11mm 4,2mm 18mm 9,8mm 19,1mm MONTAGE Montieren Sie den Tonabnehmer mit dem mitgelieferten Abbildung 1 Inbusschlüssel und dem Satz 2,5mm-Schrauben am Headshell des Tonarms. Stellen Sie ihn auf die für Ihr x2 x2 Plattenspielersystem vorgeschlagene Nadelposition ein (siehe Abbildung 1). Ausgangsanschlüsse sind für... -
Seite 5: Contenuto Confezione
La Machiavelli MkII è una delle migliori testine MC a Livello di uscita Dimensioni diamante bassa uscita che abbiamo mai progettato, frutto della 0.4mV 5×20µm pluridecennale esperienza di Gold Note nel campo Risposta in frequenza Bobine della riproduzione del vinile. 10 - 40000Hz Rame... -
Seite 6: Istruzioni Di Montaggio
25,9mm 12,7mm 11mm 4,2mm 18mm ISTRUZIONI DI MONTAGGIO 9,8mm 19,1mm Montare la testina sullo shell utilizzando la chiave a brugola e il set di viti da 2,5 mm in dotazione. Seguire le istruzioni del giradischi o del braccio che si sta utilizzando avendo cura di non inclinare né...
