HumanCentric 101-2025 Montageanleitung

Model 101-2025
ENGLISH
Wall Mount for Bose®
SoundTouch 300 Soundbar
Parts included
Mounting brackets
2
2
Installation screws
1
Cord Cover
M4 Cord Cover Mounting Screws
2
M4 Cord Cover Drywall Anchors
2
VHB Mounting Tape
1
M5 Soundbar stud mounting
screws
4
M5 Soundbar mounting screws
(drywall)
4
M5 Soundbar drywall anchors
4
Tools needed for
installation
Phillips head screwdriver
1/4 inch diameter drill bit for M5
screws
7/32 inch diameter drill bit for
M4 screws
Power drill
Hammer
